Запчасти Doosan Daewoo ENGINE CONTROL ASSY BODY PARTS

-

201-00132A

ENGINE CONTROL ASSY

SC: D

-2шт.

1

2197-1777A

BRACKET

desc: SUPPORT

1шт.

2

S0711853

BOLT M10X1.25X20

desc: BOULON A 6PANS

2шт.

3

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

4

S0504553

BOLT M6X1.0X14

desc: BOULON A 6PANS

3шт.

5

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

3шт.

6

2150-1122

HOOK;CABLE

desc: CROCHET

1шт.

7

133-00172

LEVER

desc: LEVIER

1шт.

8

S4012533

NUT M8X1.25

desc: ECROU

3шт.

9

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

9шт.

10

195-02079

BRACKET

desc: SUPPORT

1шт.

11

2138-9006B

JOINT;BALL M5X0.8

desc: ENSEMBLE DE JOINT

1шт.

12

523-00006

MOTOR;E/G CONTROL

desc: CONTROL REGIME

1шт.

13

2523-9016

MOTOR;E/G STOP

desc: ARRET MOTEUR

1шт.

14

159-00227

COVER

desc: COUVERCLE

1шт.

15

S0508953

BOLT M8X1.25X22

desc: BOULON A 6PANS

6шт.

16

S5010513

WASHER;PLAIN M8

desc: RONDELLE M8

2шт.

17

2120-2196D2

BOLT M10X1.5X25

desc: BOULON A 6PANS

2шт.

19

195-02148

BRACKET;E/G STOP MOTOR

desc: SUPPORT

1шт.

20

120-00276

BOLT M8X1.25X12

desc: BOULON A 6PANS

3шт.

21

2124-1509D10

CLIP

desc: ATTACHE

2шт.

22

2120-2196D10

BOLT;SET M12X1.75X25

desc: BOULON A 6 PANS

2шт.

24

2139-6055D16

CABLE:CONTROL 3800L

desc: CABLE: COMMANDE

1шт.

25

2124-1509D1

CLIP

desc: ATTACHE

1шт.

26

S4012233

NUT M5X0.8

desc: ECROU

1шт.

27

S5102203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE

1шт.

28

195-02157

BRACKET

desc: SUPPORT

1шт.

29

S0509353

BOLT M8X1.25X35

desc: BOULON A 6PANS

2шт.
