Запчасти Doosan Daewoo FUEL FILLER PUMP OPTION PART

-

2401-1300

PUMP ASS'Y(OPT)

SC: D

-2шт.

1

2401-1277

PUMP;FUEL TRANSFER

SERIAL: 1001-1116

1шт.

1

2401-1277A

PUMP;FUEL TRANSFER

SERIAL: 1117

1шт.

1A

2181-2755A

ADAPTER

desc: . RACCORD ADAPTATEUR

2шт.

1A

2181-2755B

ADAPTER

desc: . RACCORD ADAPTATEUR

2шт.

1B

S8180321

WASHER;SEAL

desc: . BAGUE D'ETANCHEITE

2шт.

1C

523-00002

MOTOR

desc: . MOTEUR

1шт.

1D

407-00001

VANE KIT

desc: . KIT DE VANE

1шт.

1E

2401-1276KT

SEAL KIT

desc: . KIT D'ETANCHEITE

1шт.

1F

2549-9096

SWITCH;TOGGLE

desc: . INTERRUPTEUR

1шт.

2

2185-1754D4

HOSE-2000L

SERIAL: 1001-1116

1шт.

2

2185-1247D126

HOSE-2000L

SERIAL: 1117

1шт.

3

2185-1755D3

HOSE ASS'Y-4000L

SERIAL: 1001-1116

1шт.

3

185-00167D3

HOSE ASS'Y-4000L

SERIAL: 1117

1шт.

3B

2420-1258

VALVE;CHECK

desc: . CARTOUCHE DE VANNE

1шт.

3C

2471-1152

STRAINER

desc: . FILTRE

1шт.

3D

2160-1336

CAP;STRAINER

desc: . CHAPEAU

1шт.

4

2140-1391

PIPE

desc: TUYAU

1шт.

5

S8450023

CLAMP;HOSE

desc: COLLIER

3шт.

6

S0508553

BOLT M8X1.25X14

desc: BOULON A 6 PANS

4шт.

7

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

4шт.

8

S2212661

BOLT;SOCKET M10X1.5X50

SERIAL: 1001-1197

4шт.

8

S2212666

BOLT;SOCKET M10X1.5X50

SERIAL: 1198

4шт.

9

2180-1026D2

O-RING

desc: JOINT TORIQUE

1шт.
