Запчасти Doosan Daewoo ARM PIPING-ARM 2.4M 1 & 2 WAY(ARTI.BOOM) OPTION PART

-

400-00378

ARM PIPING-2.4m

SERIAL: 1097

-2шт.

1

2140-1679

PIPE

desc: TUYAU

2шт.

2

2184-1196D161

HOSE PF1-1680L

desc: TUYAU FLEXIBLE

2шт.

3

S8000291

O-RING

desc: JOINT TORIQUE

6шт.

4

S8030161

O-RING

desc: JOINT TORIQUE

8шт.

5

2124-1026D3

CLAMP;PIPE

desc: ATTACHE DE TUBE

4шт.

6

S0560953

BOLT M12X1.75X60

desc: BOULON A 6 APNS

4шт.

7

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

8шт.

8

2420-9628

VALVE;STOP

SERIAL: 1097-1163

2шт.

8

2420-9628A

VALVE;STOP

SERIAL: 1164

2шт.

9

2124-1695

CLAMP;STOP

desc: ATTACHE DE TUYAU

2шт.

10

2181-2566D8

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

11

2181-2816D2

ELBOW

desc: COUDE

2шт.

12

2181-2817D2

CAP

desc: CHAPEAU

2шт.

13

2181-4133D6

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

14

S0561353

BOLT M12X1.75X80

desc: BOULON A 6 PANS

4шт.

20

2191-1799D78

SEAT;SCREW

desc: SIEGE

4шт.

21

2191-1067D180

SEAT;SCREW

desc: SIEGE

2шт.
