WATER PUMP & COOLING FAN

Запчасти Doosan Daewoo WATER PUMP & COOLING FAN ENGINE PARTS

101
120
110
107
103
104
108
109
105
106
118
102
124
114
120
117
116
202
115
201
113
115
112
204
203
209
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

101

65.06500-6402A

WATER PUMP ASS'Y

SERIAL: 030507

1шт.

101

65.06500-6402B

WATER PUMP ASS'Y

SERIAL: 030508

1шт.

102

65.06501-0217A

HOUSING

SC: D

1шт.

103

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

104

65.93410-0027

BEARING

desc: . PALIER

1шт.

105

06.29020-0132

RING;SNAP

desc: . BAGUE ELASTIQUE

1шт.

106

65.06504-0033

HUB;V-BELT PULLEY

desc: . MOYEU

1шт.

107

65.06506-0085A

IMPELLER

desc: . TURBINE

1шт.

108

65.06512-0016

COVER

desc: . COUVERCLE

1шт.

109

65.06901-0035

GASKET

SERIAL: 030507

1шт.

109

65.06901-0035A

GASKET

SERIAL: 030508

1шт.

110

06.04200-9009

SCREW;CROSS M8X20

desc: . VIS

3шт.

112

06.01493-4215

BOLT M10X1.25X80

desc: BOULON A 6 PANS

1шт.

113

06.01493-4212

BOLT M10X1.25X65

desc: BOULON A 6 PANS

2шт.

114

06.01943-3218

BOLT ASS'Y M10X1.25X35

desc: BOULON A 6 PANS

1шт.

115

06.16731-2108

WASHER;SPRING

desc: RONDELLE

3шт.

116

65.06606-0040

PULLEY;FAN

SERIAL: 991229

1шт.

116

65.06606-0039

PULLEY;FAN

SERIAL: 991230

1шт.

116

65.06606-0054

PULLEY;FAN(FOR EUROPE)

desc: POLLEY

1шт.

116

65.06606-0021

PULLEY(HIGH LAUDS EXPORT)

desc: POLLEY

1шт.

117

65.06901-0002

GASKET

SERIAL: 970201

1шт.

117

65.06901B0002

GASKET

SERIAL: 970202

1шт.

118

65.06301-0463A

PIPE;COOLING WATER

SERIAL: 991229

1шт.

118

65.96301-0312

HOSE;RUBBER

SERIAL: 991230

1шт.

120

06.67020-0104

CLAMP;HOSE

SERIAL: 991229

8шт.

120

06.67020-0104

CLAMP;HOSE

SERIAL: 991230

4шт.

124

65.06301-0464A

PIPE;COOLING WATER

SERIAL: 991229

1шт.

124

65.96301-0311

HOSE;RUBBER

SERIAL: 991230

1шт.

201

65.06601-5049

FAN;COOLING

SERIAL: 970815

1шт.

201

65.06601-5051

FAN;COOLING

SERIAL: 970816

1шт.

202

65.06611-0097

FLANGE;FAN

SERIAL: 970815

1шт.

202

65.06611-0108

FLANGE;FAN

SERIAL: 970816

1шт.

203

06.01013-9124

BOLT M8X95

SERIAL: 970815

4шт.

203

06.01013-9127

BOLT M8X120

SERIAL: 970816

4шт.

204

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

209

65.96801-0124

BELT

ICA: Y

1шт.

209

65.96801-0141

BELT(HIGH LAUDS EXPORT)

desc: COURROIE

1шт.
