Запчасти Doosan Daewoo SWING MOTOR(1-2) HYDRAULIC PARTS

-

K9000352

SWING MOTOR

desc: MOTEUR D'ORIENTATION

1шт.

10

K9000460

PISTON ASS'Y(121.122)

desc: ENSEMBLE CLAPET DE DECHARGE

1шт.

121

-

PISTON

SC: D

9шт.

122

-

SHOE

SC: D

9шт.

20

K9000461

VALVE CASING ASS'Y(303.451)

desc: VALVE CASING ASS'Y(303. 451)

1шт.

303

-

CASING VALVE

SC: D

1шт.

451

-

PIN

SC: D

2шт.

101

K9000462

SHAFT;DRIVE

desc: SHAFT;DRIVE

1шт.

111

K9000463

CYLINDER

desc: CYLINDER

1шт.

114

K9000464

SPRING;PLATE

desc: RESSORT

1шт.

123

K9000465

PLATE;SET

desc: PLAQUE

1шт.

124

K9000466

PLATE;SHOE

desc: PLAQUE

1шт.

131

K9000467

PLATE;VALVE

desc: PLAQUE

1шт.

301

K9000468

CASING

desc: CARTER

1шт.

351

2.424-00021

PLUNGER

desc: PLUNGEUR

2шт.

355

2.131-00165

SPRING

desc: RESSORT

2шт.

390

2.190-00012

PLATE

desc: PLAQUE

1шт.

391

1.123-00018

PIN

desc: GOUPILLE

2шт.

401

S2227561

SCREW

desc: BOULON A 6 PANS CREUX

4шт.

443

2.109-00214

BEARING;ROLLER

desc: ROULEMENT A BILLES

1шт.

444

1.109-00108

BEARING;ROLLER

desc: ROULEMENT A BILLES

1шт.

469

2.181-00266

PLUG

desc: BOUCHON VP

2шт.

472

2.180-00477

O-RING

SC: K

1шт.

488

S8000281

O-RING

SC: K

2шт.

491

K9000469

SEAL;OIL

SC: K

1шт.

702

K9000470

PISTON;BRAKE

desc: PISTON

1шт.

706

2.180-00478

O-RING

SC: K

1шт.

707

2.180-00479

O-RING

SC: K

1шт.

712

K9000471

SPRING;BRAKE

desc: RESSORT

24шт.

742

K9000472

PLATE;FRICTION

desc: PLAQUE

3шт.

743

K9000473

PLATE;SEPARATOR

desc: PLAQUE

4шт.

984

2.181-00472

PLUG;MASKING

desc: BOUCHON

1шт.

985

2.181-00471

PLUG;MASKING

desc: BOUCHON

3шт.

993

2181-1116D2

PLUG

desc: BOUCHON

1шт.

994

2181-1116D5

PLUG

desc: BOUCHON

1шт.

31

K9000474

VALVE;TIME DELAY

desc: VANNE

1шт.

31-1

-

PLUG;MASKING

SC: D

2шт.

33

S2206061

SCREW;HEX

desc: VIS

3шт.

51

K9000475

VALVE;RELIEF

desc: VANNE

2шт.

51-1

S8010301

O-RING

desc: JOINT TORIQUE

2шт.

81

K9000476

SEAL KIT(472.488.491.706.707)

desc: KIT DE REPARATION

1шт.

52

2.421-00255

VALVE;RELIEF

desc: VANNE

1шт.

100

2.423-00093

CASING

desc: CARTER

1шт.

151

2181-1890D2

PLUG

desc: BOUCHON

2шт.

161

S8000111

O-RING

desc: JOINT TORIQUE

2шт.

162

S8000121

O-RING

desc: JOINT TORIQUE

2шт.

163

S8000061

O-RING

desc: JOINT TORIQUE

2шт.

171

S2209771

SCREW

desc: VIS

4шт.

400

2.421-00324

VALVE;SWING REACTIONLESS

desc: VANNE

2шт.

400-1

S8000201

O-RING

desc: . JOINT TORIQUE

2шт.

400-2

S8060201

RING;BACK UP

desc: . BAGUE

2шт.
