Запчасти Doosan Daewoo BUCKET ASSY-0.8§© FRONT PARTS
1
8
5
9
7
7
9
6
8
1A
2
4
3
7
6
9
8
-
2704-1365A
BUCKET ASS'Y-0.8§©
SERIAL: 1-47
1шт.
-
2704-1365B
BUCKET ASS'Y-0.8§©
SERIAL: 48-166
1шт.
-
2704-1365C
BUCKET ASS'Y-0.8§©
SERIAL: 167-296
1шт.
-
2704-1365E
BUCKET ASS'Y-0.8§©
SERIAL: 297-1070
1шт.
-
2704-1365G
BUCKET ASS'Y-0.8§©
SERIAL: 1071-2537
1шт.
-
2704-1365H
BUCKET ASS'Y-0.8§©
SERIAL: 2538
1шт.
1
2704-1366A
BUCKET-0.8§©
SERIAL: 1-47
1шт.
1
2704-1366B
BUCKET-0.8§©
SERIAL: 48-296
1шт.
1
2704-1366C
BUCKET-0.8§©
SERIAL: 297-1070
1шт.
1
2704-1366E
BUCKET-0.8§©
SERIAL: 1071
1шт.
1A
2713-1218
ADAPTER;TOOTH
desc: . RACCORD
5шт.
2
2713-1217
POINT;TOOTH
SERIAL: 1-2537
5шт.
2
K1000344
POINT;TOOTH
SERIAL: 2538
5шт.
3
2705-1020
PIN;LOCKING
desc: BROCHE DE BLOCAGE
5шт.
4
2114-1848A
WASHER;LOCKING
desc: RONDELLE D'ARRET
5шт.
5
2713-1059
CUTTER;SIDE(RH)
SERIAL: 1-1070
1шт.
5
2713-1059A
CUTTER;SIDE(RH)
SERIAL: 1071
1шт.
6
2713-1060
CUTTER;SIDE(LH)
SERIAL: 1-1070
1шт.
6
2713-1060A
CUTTER;SIDE(LH)
SERIAL: 1071
1шт.
7
S0570161
BOLT M20X2.5X65
SERIAL: 1-1070
10шт.
7
S0574761
BOLT M24X3.0X70
SERIAL: 1071
10шт.
8
S4013133
NUT M20X2.5
SERIAL: 1-1070
10шт.
8
S4013333
NUT M24X3.0
SERIAL: 1071
10шт.
9
S5103101
WASHER;SPRING
SERIAL: 1-166
10шт.
9
2114-9012
WASHER;HARDEN
SERIAL: 167-1070
10шт.
9
2114-1831
WASHER;HARDEN
SERIAL: 1071
10шт.
