Запчасти Doosan Daewoo INTAKE & EXHAUST MANIFOLD ENGINE PARTS

101

65.08101-6058

MANIFOLD;EXHAUST

SERIAL: 980916

1шт.

101

65.08101-0535

MANIFOLD;EXHAUST

SERIAL: 020821

1шт.

101

65.08101-0199

MANIFOLD;EXHAUST

SERIAL: 020822

1шт.

102

06.06175-8206

BOLT;STUD M10X1.25X25

SERIAL: 001012

3шт.

103

06.06175-8208

BOLT;STUD M10X1.25X30

SERIAL: 001012

1шт.

103

06.06175-8208

BOLT;STUD M10X1.25X30

SERIAL: 001013

4шт.

104

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

12шт.

105

06.15010-2311

WASHER

desc: RONDELLE

12шт.

106

06.11063-8214

NUT

desc: ECROU

12шт.

107

65.08901-0001

GASKET;MANIFOLD EXHAUST

SERIAL: 020821

3шт.

107

65.08901-0028

GASKET;MANIFOLD EXHAUST

SERIAL: 020822

3шт.

201

65.08201-6002

MANIFOLD;INTAKE

SERIAL: 990321

1шт.

201

65.08201-5056

MANIFOLD;INTAKE

SERIAL: 990322

1шт.

212

06.01923-3115

BOLT ASS'Y

desc: BOULON A 6 PANS

8шт.

214

06.11063-8214

NUT

desc: ECROU

3шт.

215

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

216

06.15010-2311

WASHER

desc: RONDELLE

3шт.

219

65.08902-0004

GASKET;INTAKE MANIFOLD

SERIAL: 970218

1шт.

219

65.08902A0004

GASKET;INTAKE MANIFOLD

SERIAL: 970219

1шт.

301

65.09100-7040

TURBO CHARGER ASS'Y

SERIAL: 020821

1шт.

301

65.09100-7040A

TURBO CHARGER ASS'Y

SERIAL: 020822

1шт.

302

06.06225-0708

BOLT;STUD M8X30

SERIAL: 040916

4шт.

302

65.90201-0096

BOLT;STUD M8X30

SERIAL: 040917

4шт.

303

06.11063-8214

NUT

desc: ECROU

4шт.

304

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

305

65.97480-0135

HOLDER

desc: POSSESSEUR

1шт.

306

06.11024-9202

NUT

desc: ECROU

4шт.

307

06.16731-2108

WASHER;SPRING

desc: RONDELLE

4шт.

308

65.98155-0011

UNION;HOLLOW

desc: GRAISSEUR

1шт.

309

65.98130-0200

ADAPTER

SERIAL: 020813

1шт.

309

65.98130-0200A

ADAPTER

SERIAL: 020814

1шт.

310

06.56190-0709

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

311

65.05701-5342

OIL PIPE ASS'Y

desc: CONDUITE

1шт.

312

06.01913-3110

BOLT ASS'Y

desc: BOULON A 6 PANS

1шт.

313

06.78144-2403

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

314

06.56190-0704

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

315

65.05701-5343

PIPE;OIL

desc: CONDUITE

1шт.

316

65.08202-0246A

PIPE;INLET

desc: CONDUITES

1шт.

317

65.96301-0279

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

318

06.67020-0109

CLAMP;HOSE

desc: COLLIER

2шт.

319

65.96601-0045A

GASKET

desc: JOINT

1шт.

320

06.01913-3115

BOLT ASS'Y

desc: BOULON A 6 PANS

6шт.

321

65.96301-0280A

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

322

06.67020-0106

CLAMP;HOSE

desc: COLLIER

2шт.

323

65.09901-0019

GASKET

SERIAL: 020821

1шт.

323

65.09901-0018A

GASKET

SERIAL: 020822

1шт.

325

65.09901-0020

GASKET

desc: JOINT

1шт.

327

06.56180-0714

RING;SEAL

desc: BAGUE D'ETANCHEITE

2шт.

328

06.12172-9314

NUT;CAP

desc: CHAPEAU DE ECROU

1шт.

334

65.09904-0008

GASKET

desc: JOINT

1шт.

401

65.09501-7002

INTER COOLER ASS'Y

desc: REFREGERATOR

1шт.

402

06.01923-3113

BOLT ASS'Y M8X20

SERIAL: 021008

18шт.

402

06.01923-3113

BOLT ASS'Y M8X20

SERIAL: 021009

17шт.

403

65.09905-0003

GASKET;INTER COOLER

SERIAL: 030207

1шт.

403

65.09905-0006

GASKET;INTER COOLER

SERIAL: 030208

1шт.

404

06.01923-3114

BOLT ASS'Y M8X22

SERIAL: 021009

1шт.
