Запчасти Doosan Daewoo BUCKET ASSY-0.95§© HD TYPE OPTION PARTS

-

2704-1648

BUCKET ASS'Y-0.95§© H.D TYPE

desc: ENSEMBLE GODET

1шт.

1

2704-1649

BUCKET -0.95§© H.D TYPE

desc: GODET

1шт.

1A

2713-1218

ADAPTER;TOOTH

desc: . ADAPTATEUR

5шт.

2

2713-1269

POINT;TOOTH

desc: DENT

5шт.

3

2705-1020

PIN;LOCKING

desc: BROCHE DE BLOCAGE

5шт.

4

2114-1848A

WASHER;LOCK

desc: RONDELLE D'ARRET

5шт.

5

2713-1059

CUTTER;SIDE(R)

SERIAL: 1-50450

1шт.

5

2713-1059A

CUTTER;SIDE(R)

SERIAL: 50451

1шт.

6

2713-1260

CUTTER;SIDE(L)

SERIAL: 1-50450

1шт.

6

2713-1260A

CUTTER;SIDE(L)

SERIAL: 50451

1шт.

7

S0570361

BOLT M20X1.5X70

SERIAL: 1-50450

10шт.

7

S0574861

BOLT M24X3.0X75

SERIAL: 50451

10шт.

8

S4013133

NUT M20X2.5

SERIAL: 1-50450

10шт.

8

S4013333

NUT M24X3.0

SERIAL: 50451

10шт.

9

2114-9012

WASHER;HARDEN M20

SERIAL: 1-50450

10шт.

9

2114-1831

WASHER;HARDEN

SERIAL: 50451

10шт.
