Запчасти Doosan Daewoo PEDAL VALVE HYDRAULIC PARTS

-

2420-9501A

PEDAL VALVE

SERIAL: 1-50390

1шт.

*

VZ023680-1307

CASING SUB ASS'Y

desc: CARTER

1шт.

101

VZ33170-0495

CASING

desc: . BOITIER

1шт.

301

5DC81X00A-301

SPOOL

desc: . BOBINE

4шт.

151

PBP116-2403

PLUG

desc: BOUCHON

2шт.

201

VZ33140-0255

COVER

desc: COUVERCLE

2шт.

202

VZ03560-0264

PLUG

desc: BOUCHON

4шт.

203

VZ02230-0002

GREASE CAP

desc: CHAPEAU

4шт.

*

VZ03385-0041

SEAL KIT(210 . 212)

desc: KIT DE REPARATION

1шт.

210

VZ03385-0039

PACKING

desc: . JOINT

4шт.

212

OORA025

O-RING AS568-025

desc: . JOINT TORIQUE

4шт.

214

VZ33420-0089

ROD;PUSH

desc: TIGE

4шт.

215

5DT01X00-215

WASHER

desc: RONDELLE PLATE

8шт.

217

5DT01X00-217

WASHER

desc: RONDELLE PLATE

4шт.

218

VZ03270-0052

SEAT;SPRING

desc: RESSORT DE SIEGE

4шт.

221

VZ03310-0010

RING;RETAINING

desc: BAGUE

4шт.

223

VZ33340-0035

BUSH

desc: COUSSINET

4шт.

224

VZ33330-0080

PISTON

desc: PISTON

4шт.

225

ODW3-0

BALL;STEEL

desc: BILLE

12шт.

271

VZ03620-0059

SCREW

desc: VIS

2шт.

311

VZ03270-0054

SEAT;SPRING

desc: RESSORT DE SIEGE

4шт.

313

5DC81X01-313

WASHER

desc: RONDELLE

4шт.

324

5DC81X28-324

SPRING

desc: RESSORT

4шт.

335

5DC81X08-335

SPRING

desc: RESSORT

4шт.

336

VZ03340-0412

SPRING

desc: RESSORT

4шт.

337

VZ03340-0418

SPRING

desc: RESSORT

4шт.

412

ODU1010

BUSH

desc: DOUILLE

4шт.

413

5DC81X00-413

CAM SHAFT

desc: ARBRE A CAMES

2шт.

420

5DC81X01-420

CAM

desc: CAME

2шт.

423

OSSSM66

SET SCREW

desc: VIS

2шт.

471

5DC81X01-471

SET SCREW

desc: VIS

4шт.

472

5DC81X00-472

NUT;LOCK

desc: ECROU DE BLOCAGE

4шт.

501

5DC81X01-501

BELLOWS

desc: SOUFFLET

2шт.
