Запчасти Doosan Daewoo FUEL FILTER(SEDIMENTOR+FILTER) OPTION PARTS

-

2471-1151

FUEL FILTER(SEDIMENTOR+FILTER)

SERIAL: 2100

-2шт.

1

2474-9403

SEDIMENTOR

desc: SEDIMENTEUR

1шт.

2

S0555953

BOLT M8X1.5X30

desc: BOULON A 6 PANS

2шт.

3

S5010513

WASHER;PLAIN M8

desc: RONDELLE M8

4шт.

4

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

4шт.

5

S8180211

WASHER;COPPER

desc: RONDELLE

2шт.

6

2181-4123

PIPE;FUEL

desc: RACCORD

2шт.

7

S8450012

CLAMP;HOSE

desc: COLLIER

6шт.

8

2185-1247D77

HOSE 2600L

desc: TUYAU FLEXIBLE

1шт.

9

2185-1247D105

HOSE 1500L

desc: TUYAU FLEXIBLE

1шт.

10

2181-9015

PIPE;FUEL

desc: CANALISATION DE GAZOLE

3шт.

11

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

2шт.

12

2124-1509D2

CLIP

desc: ATTACHE

2шт.

13

2124-1084D4

CLIP;BAND

desc: COLLIER

1шт.

14

2471-9053

FUEL FLTER ASS'Y

desc: FILTRE A GAZOLE

1шт.

14-1

65.12504-5013A

HEAD

desc: . COUVERCLE

1шт.

14-2

65.12503-5011A

CARTRIDGE;FUEL FILTER

desc: . FILTRE A GAZOLE

1шт.

14-3

65.90310-0143

SCREW;PLUG

desc: . VIS

1шт.

14-4

06.56180-0716

RING;SEAL

desc: . BAGUE D'ETANCHEITE

1шт.

15

S0558253

BOLT M10X1.5X35

desc: BOULON A 6 PANS

2шт.

16

S5010613

WASHER;PLAIN M10

desc: RONDELLE

2шт.

17

2120-9013

SCREW;HOLLOW(M14X1.5X26)

desc: VIS

2шт.

18

S8180221

WASHER;CPPER M14

desc: RONDELLE D'ETANCHEITE

4шт.

19

2185-1247D123

HOSE 400L

desc: TUYAU FLEXIBLE

1шт.
