Запчасти Doosan Daewoo REMOTE CONTROL VALVE(2) HYDRAULIC PARTS

|$1

2420-9096A

VALVE;REMOTE CONTROL

SERIAL: 1-24

1шт.

101

5DC82X00-101

CASING

desc: . CARTER

2шт.

111

5DC82X00-111

SPACER

desc: . DOUILLE D'ECARTEMENT

1шт.

112

OORBP12

O-RING

REP_PNO: 201694

4шт.

113

OSBM845

SCREW

desc: . VIS

4шт.

114

VZ50101400

PLUG

desc: . BOUCHON

4шт.

201

5DC81X00C-201

COVER

desc: . COUVERCLE

2шт.

202

5DC81X01-202

PLUG

desc: . BOUCHON

4шт.

210

5DT61X20-213

SEAL

REP_PNO: 211700

4шт.

211

5D06X00-211

SCRAPER

desc: . GRATTER

4шт.

212

OORBP20

O-RING

REP_PNO: 201713

4шт.

214

5DC81X01-212

ROD;PUSH

desc: . TIGE

4шт.

215

5DT01X00-215

WASHER 1

desc: . RONDELLE

8шт.

217

5DC01X00-217

WASHER 2

desc: . RONDELLE

4шт.

271

5DC81X00-271

SCREW

desc: . VIS

4шт.

301

5DC81X00A-301

SPOOL

desc: . BOBINE

4шт.

311

5DC81X00-311

SEAT;SPRING

desc: . SIEGE

4шт.

313

5DC81X00-313

WASHER 3

desc: . RONDELLE

4шт.

324

5DC81X09-324

SPRING

desc: . RESSORT

4шт.

335

5DC81X14-335

SPRING

desc: . RESSORT

4шт.

412

ODU1010

BUSH

desc: . DOUILLE

4шт.

413

5DC81X00-413

SHAFT;CAM

desc: . ARBRE

2шт.

420

5DC81X01-420

CAM

desc: . ARBRE A CAMES

2шт.

423

OSSSM66

SCREW;SET

desc: . VIS

2шт.

471

5DC81X01-471

SCREW;SET

desc: . VIS

4шт.

472

5DC81X00-472

NUT;LOCK

desc: . ECROU

4шт.

501

5DC81X01-501

BELLOWS

desc: . SOUFFLET

2шт.

520

5DC81X00-520

PEDAL

desc: . PADALE

2шт.

521

5DC81X00-521

COVER;PEDAL

desc: . COUVERCLE

2шт.

522

VZ50105927-01

SCREW

desc: . VIS

4шт.
