Запчасти Doosan Daewoo REMOTE CONTROL VALVE(1-3) HYDRAULIC PARTS

-

2420-9359A

VALVE;REMOTE CONTROL(L.H.)

SERIAL: 1231-1420

1шт.

-

2420-9360A

VALVE;REMOTE CONTROL(R.H.)

SERIAL: 1231-1420

1шт.

1

J95C1001

CASE

desc: CARTER

1шт.

2

WPT18

PLUG

desc: BOUCHON

4шт.

3

J95C1002

PLUG

desc: BOUCHON

1шт.

4

P0014

O-RING

desc: JOINT TORIQUE

1шт.

5

J95C1003

SPOOL

desc: BOBINE

4шт.

6

J95C1004

SHIM

desc: CALE

-2шт.

7

J95C1005

SPRING

desc: RESSORT

4шт.

8

J95C1006

SEAT;SPRING

desc: SIEGE

4шт.

9

J24D2011

STOPPER

desc: ARRET

4шт.

10

J95C1007

SPRING

desc: RESSORT

4шт.

11

J95C1008

PLUG

desc: BOUCHON

4шт.

12

RSY10

SEAL;ROD

desc: JOINT

4шт.

13

P0020F

O-RING

desc: JOINT TORIQUE

4шт.

14

J95C1009

ROD;PUSH

desc: TIGE DE POUSSOIR

4шт.

15

J95C1010

PLATE

desc: PLAQUE

1шт.

16

J95C1011

BUSHING

desc: DOUILLE

1шт.

17

J95C1012

JOINT ASS'Y

desc: ENSEMBLE DE JOINT

1шт.

18

J95C1013

PLATE;SWASH

desc: PLAQUE

1шт.

19

J95C1014

NUT;HEX

desc: ECROU

1шт.

20

J95C1015

CONNECTOR

desc: BIELLE

1шт.

21

HNM14-1

NUT

desc: ECROU

1шт.

22

SR12ES

RING;SNAP

desc: BAGUE

1шт.

23

HNM12-1

NUT

desc: ECROU

1шт.

24

J95C1016

BELLOWS

desc: SOUFFLET

1шт.

25

J95C1017

SWITCH ASS'Y

desc: INTERRUPTEUR

1шт.

26

J95C1018

ROLLER

desc: GALET

1шт.

27

J95C1019

COVER;SWITCH

desc: COUVERCLE

1шт.

28

J95C1020

COVER;SWITCH

desc: COUVERCLE

1шт.

29

J95C1021

COVER

desc: COUVERCLE

1шт.

30

SAM0407

SCREW

desc: VIS

1шт.

31

WPM04

WASHER;PLATE

desc: RONDELLE

1шт.

32

WPM12

WASHER;PLATE

desc: RONDELLE

1шт.

33

P0010A

O-RING

desc: JOINT TORIQUE

1шт.

*

TH40K-LH

HANDLE BAR CASE ASS'Y(LH)

SC: S

1шт.

*

TH40K-RH

HANDLE BAR CASE ASS'Y(RH)

SC: S

1шт.
