Запчасти Doosan Daewoo CENTER JOINT HYDRAULIC PARTS

-

2480-6043

CENTER JOINT

SERIAL: 1621

1шт.

1

2483-6002

BODY

desc: CARTER

1шт.

2

2481-6007

SPINDLE

desc: BROCHE

1шт.

3

2482-6002

COVER

desc: COUVERCLE

1шт.

4

SJD-100-40

SPACER

desc: BAGUE

1шт.

5

SJD-100-50

SHIM

desc: CALE

1шт.

6

SJD-100-60

SHIM

desc: CALE

1шт.

7

SJD-100-70

SEAL;SLIPPER

desc: JOINT

6шт.

8

SJD-100-80

O-RING 1AP-120

desc: JOINT TORIQUE

1шт.

9

SJD-100-90

O-RING 1BP-100

desc: JOINT TORIQUE

1шт.

10

SJD-100-100

O-RING 1BG-120

desc: JOINT TORIQUE

1шт.

11

SJD-100-110

PLUG PT3/4

desc: BOUCHON

4шт.

12

SJD-100-120

RING;RETAINING

desc: BAGUE

1шт.

13

SJD-100-130

BOLT M12X1.75X30

desc: BOULON A 6 PANS

4шт.

14

SJD-100-140

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.
