Запчасти Doosan Daewoo FUEL FILTER ENGINE PARTS

|$1

65.12501-7001

FUEL FILTER ASS'Y

SERIAL: 1-2005

1шт.

1

65.12503-5001

ELEMENT;FUEL FILTER(PRIMARY)

desc: . ELEMENT FILTRANT

1шт.

2

65.12503-5003

ELEMENT;FUEL FILTER(SECONDARY)

desc: . ELEMENT FILTRANT

1шт.

3

65.12504-5001

COVER;FUEL FILTER

desc: . COUVERCLE

1шт.

4

65.12506-0003

PACKING;FUEL FILTER

desc: . RONDELLE D'ETANCHEITE

2шт.

5

06.01014-9120

BOLT;HEX. M8X75

desc: . BOULON A 6 PANS

2шт.

6

06.56180-0811

RING;SEAL A8X12

desc: . BAGUE

2шт.

7

65.12509-5002

SCREW;BREATHER M8

desc: . VIS

2шт.

8

65.96507-0003

RING;SEAL

desc: . BAGUE

2шт.

9

65.12502-5001

HOUSING;FUEL FILTER

desc: . BOITIER

2шт.

11

06.15010-2313

WASHER 13

desc: RONDELLE 13

2шт.

11

06.15010-2313

WASHER 13

desc: RONDELLE 13

12

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE

2шт.

12

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE

13

06.01493-4306

BOLT;HEX. M12X1.5X35

desc: BOULON A 6 PANS

2шт.

13

06.01953-3318

BOLT;HEX. M12X1.5X35

desc: BOULON A 6 PANS

2шт.

14

65.93641-0007

HOSE;FUEL(INLET)

SERIAL: 400018

1шт.

14

65.96341-0097

HOSE;FUEL(INLET)

SERIAL: 400019

1шт.

15

65.96341-0052

HOSE;FUEL(OUTLET)

SERIAL: 400018

1шт.

15

65.96341-0107

HOSE;FUEL(OUTLET)

SERIAL: 400019

1шт.

16

65.90420-0004

SCREW;HOLLOW

desc: VIS

2шт.

17

06.56190-0706

RING;SEAL A14X20

desc: BAGUE

4шт.

18

65.97460-0001

CLAMP

desc: COLLIER

1шт.
