Запчасти Doosan Daewoo ELEC.PARTS& TACHOMETER DRIVE ENGINE PARTS

1

65.96801-0058

V-BELT 2XAX1575

SERIAL: 500165

1шт.

1

65.96801-0059

V-BELT 2XAX1600

SERIAL: 500166

1шт.

2

65.19102-0044

BRACKET;ALTERNATOR MOUNTING

desc: SUPPORT

1шт.

3

06.01283-7318

BOLT;HEX. M12X1.75X35

desc: BOULON A 6 PANS

1шт.

4

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE

1шт.

5

06.01283-7215

BOLT;HEX. M10X25

desc: BOULON A 6 PANS

2шт.

5

06.01914-3215

BOLT;HEX. M10X25

desc: BOULON A 6 PANS

2шт.

6

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

2шт.

6

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

7

65.90435-0004C

BOLT;ADJUST

desc: BOULON A 6 PANS

1шт.

8

65.19107-0001

PIECE;GUIDE

desc: CONNECTEUR

1шт.

9

65.93020-0025

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

10

06.11063-9217

NUT;HEX

desc: ECROU

2шт.

11

06.01494-4409

BOLT;HEX

desc: BOULON A 6 PANS

1шт.

12

06.16731-2110

WASHER;SPRING A14

desc: RONDELLE ELASTIQUE

1шт.

13

65.26201-7049

STARTER 24VX6.0KW

desc: DEMARREUR

1шт.

14

06.06225-0808

BOLT;STUD M10X30

desc: BOULON

3шт.

15

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

3шт.

16

06.11063-8215

NUT;HEX. M10

desc: ECROU

3шт.

17

65.27901-0005

GASKET(END COVER)

desc: JOINT

1шт.

18

65.91605-0005

COVER;END

desc: COUVERCLE

1шт.

18

65.91605-0009

COVER;END

desc: COUVERCLE

1шт.

19

06.56180-0708

RING;SEAL A6.5X11

desc: BAGUE

4шт.

20

06.02090-0308

BOLT;SOCKET HEAD M6X16

desc: BOULON A 6 PANS CREUX

4шт.
