Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

|$1

65.03101-6495H

CYLINDER HEAD ASS'Y

SERIAL: 9800113

3шт.

1

65.03101-0295

HEAD;CYLINDER

SC: D

3шт.

1

06.15091-0319

PLUG;CORE B28D

desc: . BOUCHON

21шт.

1

65.91001-0013

PLUG

desc: . BOUCHON

6шт.

2

65.03201-1007

GUIDE;VALVE

desc: . GUIDE

12шт.

2-1

65.03203-1029

RING;VALVE SEAT(INTAKE)

desc: . BAGUE

6шт.

2-2

65.03203-1028

RING;VALVE SEAT(EXHAUST)

desc: . BAGUE

6шт.

3

65.90020-0033A

BOLT;CYLINDER HEAD

desc: BOULON

24шт.

4

65.03901-0058

GASKET;CYLINDER HEAD

desc: JOINT

3шт.

5

65.03905-0022

GASKET;CYLINDER HEAD COVER

desc: JOINT

3шт.

6

65.03401-0021

COVER;CYLINDER HEAD

desc: COUVERCLE

1шт.

6-1

65.03401-0056

COVER;CYLINDER HEAD

desc: COUVERCLE

1шт.

7

65.03401-6044A

CYLINDER HEAD COVER ASS'Y

desc: COUVERCLE DE CULASSE

1шт.

8

65.90020-0042

BOLT;HEX

desc: BOULON A 6 PANS

6шт.

9

65.90701-0052

WASHER

desc: RONDELLE

6шт.

10

65.03905-0017

PACKING

desc: RONDELLE D'ETANCHEITE

6шт.

11

65.01801-5095A

BREATHER ASS'Y

desc: RENIFLARD

1шт.

12

65.96301-0294

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

13

65.97401-0142

CLIP;HOSE

desc: CLIP

1шт.

14

06.01923-3111

BOLT ASS'Y M8X16

desc: BOULON A 6 PANS

3шт.

15

65.96501-0033B

O-RING

desc: JOINT TORIQUE

1шт.

16

06.67020-0105

CLAMP NWS16

desc: ATTACHE

1шт.

17

65.01810-5007

CAP;OIL FILLER

desc: VIBREUR

1шт.
