Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

|$1

65.03101-6495

CYLINDER HEAD ASS'Y

SERIAL: 9800112

3шт.

1

65.03101-0295

HEAD;CYLINDER

SC: D

3шт.

1

06.15091-0319

PLUG;CORE B28D

SC: D

21шт.

1

65.91001-0013

PLUG

SC: D

6шт.

2

65.03201-1007

GUIDE;VALVE

desc: . GUIDE

12шт.

2

65.03203-1029

RING;VALVE SEAT(INTAKE)

desc: . BAGUE

6шт.

2

65.03203-1028

RING;VALVE SEAT(EXHAUST)

desc: . BAGUE

6шт.

3

65.90020-0033A

BOLT;CYLINDER HEAD

desc: BOULON

24шт.

4

65.03901-0033

GASKET;CYLINDER HEAD

desc: JOINT

3шт.

5

65.03905-0012

GASKET;CYLINDER HEAD COVER

desc: JOINT

3шт.

6

65.03401-0021

COVER;CYLINDER HEAD

desc: COUVERCLE

2шт.

7

65.03401-6017

CYLINDER HEAD COVER ASS'Y

desc: COUVERCLE DE CULASSE

1шт.

8

65.03401-0022

COVER;CYLINDER HEAD

desc: . COUVERCLE

1шт.

9

65.92911-5001

CHAIN ASS'Y

desc: . ENSEMBLE CHAINE

1шт.

10

65.01810-0001

CAP;OIL FILLER

desc: . BOUCHON

1шт.

11

65.90020-0042

BOLT;HEX

desc: BOULON A 6 PANS

6шт.

12

65.90701-0052

WASHER

desc: RONDELLE

6шт.

13

65.03905-0009

PACKING

SERIAL: 400058

6шт.

13

65.03905-0017A

PACKING

SERIAL: 400059

6шт.

14

65.97871-0238

PLATE;NAME

desc: PLAQUE

1шт.

15

65.97801-0148

PLATE;CAUTION

desc: PLAQUE

1шт.
