Запчасти Doosan Daewoo COOLING WATER PUMP ENGINE PARTS

|$1

65.06500-6080

WATER PUMP ASS'Y

SERIAL: 400043

1шт.

|$2

65.06500-6118A

WATER PUMP ASS'Y

SERIAL: 400044

1шт.

|$3

65.06500-6132

WATER PUMP ASS'Y

SERIAL: 9500166

1шт.

2

06.01913-3119

BOLT;HEX. M8X70

desc: . BOULON A 6 PANS

2шт.

5

65.06506-0043

IMPELLAR

SC: D

1шт.

6

65.06520-6007

SEAL;MECHANICAL

SC: D

1шт.

7

65.93410-0027

BEARING;UNIT

SC: D

1шт.

10

06.29020-0132

RING;SNAP 55X2

desc: . BAGUE

1шт.

11

65.06504-0030

HUB

SC: D

1шт.

12

65.06501-0064

HOUSING;WATER PUMP

SERIAL: 9500165

1шт.

12

65.06501-0064A

HOUSING;WATER PUMP

SERIAL: 9500166

1шт.

13

65.06901-0019

GASKET(WATER PUMP. INNER)

desc: . JOINT DE POMPE A EAU(INTERIEUR)

1шт.

14

65.06512-0010

COVER;WATER PUMP

desc: . COUVERCLE

1шт.

15

06.04201-8907

BOLT;CROSS-RECESSED HEAD MACHINE M6X14

desc: . BOULON A 6 PANS

3шт.

19

65.06503-0070

PULLEY;V-BELT

SERIAL: 9500165

1шт.

19

65.06503-0079

PULLEY;V-BELT

SERIAL: 9500166

1шт.

20

65.06611-0055

FLANGE

SERIAL: 9500165

1шт.

20

65.06611-0092

FLANGE

SERIAL: 9500166

1шт.

21

65.06601-0061

FAN;COOLING(STEEL.6BLADES)

SERIAL: 500165

1шт.

21

65.06601-5040

FAN;COOLING(PLASTIC.10BLADES)

SERIAL: 500166

1шт.

22

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

6шт.

23

06.01013-9140

BOLT;HEX. M8X105

SERIAL: 500165

6шт.

23

06.01013-9123

BOLT;HEX. M8X90

SERIAL: 500166

6шт.

28

65.06901-0020

GASKET(WATER PUMP. OUTER)

desc: JOINT DE POMPE A EAU(EXTERIEUR)

1шт.

29

06.01913-3113

BOLT;HEX. ASS'Y M8X40

desc: BOULONA 6 PANS

3шт.

31

06.01013-9219

BOLT;HEX. M10X70

desc: BOULON A 6 PANS

1шт.
