Запчасти Doosan Daewoo COOLING SYSTEM ENGINE PARTS

1

65.01705-0002

COVER;WATER CHAMBER

desc: COUVERCLE

1шт.

2

65.01907A0002

GASKET(WATER CHAMBER COVER)

desc: JOINT(COUVERCLE DE CHAMBRE D'EAU)

1шт.

3

06.15010-2311

WASHER 8.4

desc: RONDELLE 8.4

12шт.

4

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

12шт.

5

06.01923-3115

BOLT;HEX. M8X25

desc: BOULON A 6 PANS

14шт.

7

65.90201-0149

BOLT;STUD M8X25

desc: BOULON

12шт.

8

06.11063-8214

NUT;HEX

desc: ECROU

12шт.

9

65.06301-0102

PIPE;COOLING WATER

SERIAL: 9700317

1шт.

9

65.06301-0133

PIPE;COOLING WATER

SERIAL: 9700318

1шт.

10

65.06903-0011

GASKET(COOLING WATER PIPE)

desc: JOINT(CONDUITE D'EAU)

3шт.

12

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

6шт.

13

06.02090-0410

BOLT;SOCKET HEAD

desc: BOULON A 6 PANS CREUX

6шт.

14

06.56190-0709

RING;SEAL

desc: BAGUE

1шт.

15

06.08092-2405

SCREW;PLUG

desc: VIS

1шт.

16

66.27435-6007

SWITCH;THERMO 10

desc: INTERRUPTEUR

1шт.

17

06.67020-0109

CLAMP;HOSE NWS32

desc: COLLIER

2шт.

18

65.96301-0151

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

19

65.06401-6018

THERMOSTAT

SERIAL: 9500256

1шт.

19

65.06401-6037

THERMOSTAT

SERIAL: 9500247

1шт.

21

06.67020-0106

CLAMP;HOSE NWS20

desc: COLLIER

2шт.

26

04.27405-1910

HOSE;RUBBER 250X62X80

desc: TUYAU FLEXIBLE

2шт.

27

06.67020-0110

CLAMP;HOSE NWS40

desc: COLLIER

4шт.

28

65.06301-0083

PIPE;FROM WATER TO OIL COOLER

desc: CONDUITE

1шт.

29

65.96301-0118

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.
