Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

65.01903-0021

GASKET(TIMING GEAR CASE)

desc: JOINT(CARTER DE DISTRIBUTION)

1шт.

2

65.01304-0010

CASE;TIMING GEAR

desc: CARTER

1шт.

5

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

6шт.

5

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

1шт.

6

06.01283-7113

BOLT;HEX. M8X20

SERIAL: 940222

5шт.

6

06.01913-3113

BOLT;HEX. M8X20

SERIAL: 940223

5шт.

6-1

06.06225-0704

BOLT;STUD M8X20

desc: BOULON

1шт.

6-2

06.11063-8214

NUT;HEX. M8

desc: ECROU

1шт.

7

06.16731-2108

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

1шт.

8

06.01733-4311

BOLT;HEX. M12X1.5X30

SERIAL: 940222

4шт.

8

06.01943-3317

BOLT;HEX. M12X1.5X30

SERIAL: 940223

4шт.

9

65.90201-0048

BOLT;STUD M10X40

desc: BOULON

1шт.

10

06.06225-0809

BOLT;STUD M10X35

desc: BOULON

6шт.

11

06.06225-0810

BOLT;STUD

desc: BOULON

2шт.

12

65.01903-0113

GASKET(TIMING GEAR CASE COVER)

desc: JOINT(COUVERCLE DE CARTER DE DISTRI.)

1шт.

13

65.01305-5028B

TIMING GEAR CASE COVER ASS'Y

desc: ENSEMBLE COUVERCLE DE CARTER DE

1шт.

16

06.01923-2914

BOLT;HEX. ASS'Y M6X22

desc: BOULON A 6 PANS

13шт.

18

65.01903-0029

GASKET(TIMING GEAR CASE COVER)

desc: JOINT(COUVERCLE DE CARTER DE DISTRIBUTION)

1шт.

19

65.01307-5009

TIMING GEAR CASE COVER ASS'Y

desc: ENSEMBLE COUVERCLE DE CARTER DE

1шт.

20

06.15010-2309

WASHER 6.4

desc: RONDELLE 6.4

2шт.

21

06.16731-2105

WASHER;SPRING A6

desc: RONDELLE ELASTIQUE

2шт.

22

06.01283-6918

BOLT;HEX. M6X35

SERIAL: 940222

9шт.

22

06.01923-2918

BOLT;HEX. M6X35

SERIAL: 940223

9шт.

23

06.06225-0502

BOLT;STUD M6X16

desc: BOULON A 6 PANS

2шт.

24

06.11063-8212

NUT;HEX. M6

desc: ECROU

2шт.

25

06.22022-0908

PIN;DOWEL 6m6X10

desc: BROCHE

2шт.

25

06.22022-0907

PIN;DOWEL 6m6X12

desc: BROCHE

2шт.

26

65.01510-0018

SEAL;CRANK SHAFT(FRONT)

SERIAL: 400043

1шт.

26

65.01510-0026

SEAL;CRANK SHAFT(FRONT)

SERIAL: 400044

1шт.

27

65.54903-0013

GASKET

desc: JOINT

1шт.

28

65.54302-5013

BRACKET;AIRCON

SERIAL: 309999

1шт.

28

65.54302-5014

BRACKET;AIRCON

SERIAL: 400001

1шт.

28

65.54302-5015A

BRACKET;AIRCON

SERIAL: 500352

1шт.

29

06.02090-0511

BOLT;SOCKET HEAD

desc: BOULON A 6 PANS CREUX

4шт.

30

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

4шт.

31

65.54306-0010

BRACKET

desc: SUPPORT

1шт.

32

06.01283-7213

BOLT;HEX. M10X1.5X20

SERIAL: 9400222

2шт.

32

06.01913-3213

BOLT;HEX. M10X1.5X20

SERIAL: 9400223

2шт.

34

65.95840-0007

BRACKET;IDLE PULLEY

SERIAL: 500351

1шт.

34

65.95840-0024

BRACKET;IDLE PULLEY

SERIAL: 500352

1шт.

36

06.01283-7213

BOLT;HEX. M10X1.5X20

SERIAL: 9400222

3шт.

36

06.01913-3213

BOLT;HEX. M10X1.5X20

SERIAL: 9400223

3шт.

37

65.95800-6014

IDLE PULLEY ASS'Y

desc: ENSEMBLE POULIE FOU

1шт.

38

65.11401-5007

MOUNTING FLANGE ASS'Y

desc: ENSEMBLE SUPPORT DE MONTAGE

1шт.

39

65.11902-0006

GASKET

SERIAL: 500220

1шт.

39

65.11902-0018A

GASKET

SERIAL: 500221

1шт.

40

06.22220-1110

PIN;SPRING

desc: BROCHE

1шт.

41

06.15010-2312

WASHER;PLAIN 10.5

desc: RONDELLE

7шт.

42

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

7шт.

43

06.11063-8215

NUT;HEX. M10

desc: ECROU

7шт.

44

65.90201-0059

BOLT;STUD M10X35

desc: BOULON

4шт.

45

65.90310-0033

SCREW;PLUG M10X1.25

SERIAL: 500352

1шт.

46

06.56180-0714

RING;SEAL A10X15

SERIAL: 500352

1шт.

47

65.96801-0059

BELT;V

SERIAL: 0241

2шт.
