Запчасти Doosan Daewoo OIL PIPE-IN OIL PAN ENGINE PARTS

1

65.05701-6039B

OIL SUCTION PIPE ASS'Y

SERIAL: 9700398

1шт.

1-1

65.05701-5203B

PIPE;OIL SUCTION PIPE

desc: . CONDUITE ASPIRATION D'HUILE

1шт.

2

65.05740-0015

HOLDER;OIL SUCTION PIPE

desc: . CUVETTE DE FUSIBLE

1шт.

4

06.01923-3111

BOLT;HEX. M8X16

desc: BOULON A 6 PANS

1шт.

5

06.15010-2311

WASHER

desc: . RONDELLE

1шт.

6

06.01923-3114

BOLT;HEX. M18X1.25X22

desc: . BOULON A 6 PANS

1шт.

7

65.90510-0012

NUT;CLEVELOC M8

desc: . ECROU

1шт.

9

06.01923-3113

BOLT;HEX. M8X1.25X20

desc: BOULON A 6 PANS

2шт.

10

65.96601B0019

GASKET(OIL SUCTION PIPE)

desc: JOINT(TUBE D'ASPIRATION D'HUILE)

1шт.

11

65.05701-5153

OIL PIPE ASS'Y(O/P-C/F)

desc: ENSEMBLE TUBE D'HUILE

1шт.

12

06.56250-2002

GASKET(OIL PUMP FLANGE)

desc: JOINT

4шт.

13

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

6шт.

14

06.01283-7113

BOLT;HEX. M8X1.25X20

desc: BOULON A 6 PANS

6шт.

15

65.05903B0003

GASKET(CONNECTING FLANGE)

desc: JOINT(BRIDE DE RACCORDEMENT)

1шт.

16

65.05715-5001

CONNECTING FLANGE ASS'Y

desc: ENSEMBLE BRIDE DE RACCORDEMENT

1шт.

17

06.15010-2311

WASHER

desc: RONDELLE

2шт.

18

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

2шт.

19

06.02090-0422

BOLT;SOCKET HEAD M8X65

desc: BOULON A 6 PANS CREUX

2шт.

20

65.05701-5230

OIL PIPE ASS'Y(C/F-BLOCK)

desc: ENSEMBLE CONDUITE D'HUILE(BRIDE-BLOC)

1шт.

21

06.15010-2311

WASHER

desc: RONDELLE

2шт.

22

06.16110-0106

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

2шт.

23

06.02090-0412

BOLT;SOCKET HEAD M8X25

desc: BOULON A 6 PANS CREUX

2шт.

24

65.05801-5159

OIL PAN ASS'Y

SERIAL: 9700040

1шт.

24

65.05801-5192

OIL PAN ASS'Y

SERIAL: 9700041

1шт.

25

65.05904-0016

GASKET(OIL PAN)

desc: JOINT DE CARTER D'HUILE

1шт.

26

65.05809-0014

WASHER;OIL PAN(FRONT)

desc: RONDELLE

2шт.

27

65.05809-0012

WASHER;OIL PAN(FRONT. SIDE)

desc: RONDELLE

2шт.

28

65.05809-0013

WASHER;OIL PAN(REAR)

desc: RONDELLE

2шт.

29

65.05809-0037

WASHER;OIL PAN(REAR)

desc: RONDELLE

1шт.

30

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

12шт.

31

06.02090-0412

BOLT;SOCKET HEAD M8X20

desc: BOULON A 6 PANS CREUX

10шт.

32

06.02090-0410

BOLT;SOCKET HEAD M8X25

desc: BOULON A 6 PANS CREUX

2шт.

33

06.01913-3115

BOLT;HEX. M8X1.25X25

desc: BOULON A 6 PANS

25шт.

34

06.56190-0732

RING;SEAL A30X36

desc: BAGUE

1шт.

35

65.90310-5004

DRAIN PLUG ASS'Y

ICA: Y

1шт.

35

65.90310-0144

DRAIN PLUG ASS'Y

desc: ENSEMBLE BOUCHON DE VINDANGE

1шт.

36

65.05805-5023

GAUGE;OIL LEVEL

desc: JAUGE

1шт.

37

64.05903-0011

GASKET

SERIAL: 9700040

1шт.

38

65.91615-0009

COVER;BLIND

SERIAL: 9700040

1шт.

39

06.16731-2105

WASHER;SPRING A6

SERIAL: 9700040

4шт.

39

06.16731-2105

WASHER;SPRING A6

SERIAL: 9700040

40

06.01283-6911

BOLT;HEX. M6X16

SERIAL: 9700040

4шт.

40

06.01913-2911

BOLT;HEX. M6X16

SERIAL: 9700040

4шт.

41

65.05806-0018

TUBE;GUIDE

desc: CONDUITE

1шт.
