Запчасти Doosan Daewoo OIL COOLER ENGINE PARTS

|$1

65.05601-7137

OIL COOLER ASS'Y

SERIAL: 9800113

1шт.

1

65.05902A0011

GASKET(OIL COOLER HOUSING)

desc: JOINT(CARTER DE REFROIDISSEUR D'HUILE)

1шт.

2

65.05604-5030

HOUSING;OIL COOLER

desc: . BOITIER

1шт.

3

06.15030-0513

WASHER 8.4

desc: . RONDELLE 8.4

4шт.

4

06.16110-0106

WASHER;SPRING A8

desc: . RONDELLE ELASTIQUE

4шт.

5

06.02090-0418

BOLT;SOCKET HEAD M8X45

desc: . BOULON A 6 PANS CREUX

4шт.

6

65.96601A0018

GASKET(OIL COOLER)

desc: . JOINT(REFROIDISSEUR D'HUILE)

2шт.

7

65.05606-5020

ELEMENT;OIL COOLER(PLATE)

desc: . ELEMENT FILTRANT

1шт.

8

65.05605-6003

COVER;OIL COOLER

desc: . COUVERCLE

1шт.

9

65.05902A0008

GASKET(OIL COOLER COVER)

desc: . JOINT(COUVERCLE DE REFROIDISSEUR D'HUILE)

1шт.

10

06.01923-3126

BOLT;HEX. M8X75

desc: . BOULON A 6 PANS

8шт.

11

06.56190-0718

RING;SEAL A22X27

desc: . BAGUE

1шт.

12

65.90310-0136

SCREW;PLUG A22X1.5

desc: . VIS

1шт.

13

06.31641-0429

BALL;BY PASS

desc: . BILLE

1шт.

14

65.97601-0004

SPRING

desc: . RESSORT

1шт.

15

65.05611-0001

PIN

desc: . GOUPILLE

1шт.

16

06.56190-0728

RING;SEAL A26X32

desc: . BAGUE

1шт.

17

65.90310-0003

SCREW;PLUG M26X1.5

desc: . VIS

1шт.

18

65.90001-6011

BOLT ASS'Y M10X70

desc: BOULON A 6 PANS

2шт.

19

06.01924-3225

BOLT ASS'Y M10X70

desc: BOULON A 6 PANS

2шт.

20

65.96601-0347

GASKET

desc: JOINT

1шт.

21

65.91605-0110

COVER;BLINDER

desc: COUVERCLE

1шт.

22

06.01913-3112

BOLT ASS'Y M8X18

desc: BOULON A 6 PANS

4шт.
