Запчасти Doosan Daewoo INTAKE. EXHAUST MANIFOLD ENGINE PARTS

1

65.08201-5035

INTAKE MANIFOLD ASS'Y

SERIAL: 9500150

1шт.

1

65.08201-5035A

INTAKE MANIFOLD ASS'Y

SERIAL: 9500151

1шт.

1

65.08201-5051

INTAKE MANIFOLD ASS'Y

SERIAL: 9700000

1шт.

2

65.08902-0008

GASKET(INTAKE MANIFOLD)

SERIAL: 9500432

6шт.

2

65.08902A0024

GASKET(INTAKE MANIFOLD)

SERIAL: 9500433

6шт.

3

06.15030-0514

WASHER 10.5

desc: RONDELLE

2шт.

4

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

2шт.

5

06.06225-0809

BOLT;STUD

desc: GOUJON

2шт.

6

06.11063-8215

NUT;HEX

desc: ECROU

2шт.

10

65.08100-6031

EXHAUST MANIFOLD ASS'Y

SERIAL: 9600124

1шт.

10

65.08100-6054

EXHAUST MANIFOLD ASS'Y

SERIAL: 9600125

1шт.

11

65.08101-0095

MANIFOLD;EXHAUST(L.H)

SERIAL: 9600124

1шт.

11

65.08101-0193

MANIFOLD;EXHAUST(L.H)

SERIAL: 9600125

1шт.

12

65.08101-0149

MANIFOLD;EXHAUST(MIDDLE)

desc: . COLLECTEUR

1шт.

13

65.08101-0096

MANIFOLD; EXHAUST(R.H)

SERIAL: 9600124

1шт.

13

65.08101-0194

MANIFOLD; EXHAUST(R.H)

SERIAL: 9600125

1шт.

14

65.96501-0007

RING;SEAL

desc: . BAGUE

4шт.

15

65.08901A0013

GASKET(EXHAUST MANIFOLD)

desc: JOINT DE COLLECTEUR D'ECHAPPEMENT

6шт.

16

06.06226-0808

BOLT;STUD M10X30

desc: BOULON

6шт.

17

65.08120-5012

SCREEN;HEAT(CYLINDER HEAD)

SERIAL: 9600124

1шт.

17

65.08120-5018B

SCREEN;HEAT(CYLINDER HEAD)

SERIAL: 9600125

1шт.

18

06.15010-2312

WASHER 10.5

desc: RONDELLE 10.5

6шт.

19

06.11063-8215

NUT;HEX. M10

desc: ECROU

6шт.

20

65.90201-0049

BOLT;STUD M12X1.5

desc: BOULON

6шт.

21

06.15010-2312

WASHER 13

desc: RONDELLE 13

6шт.

22

06.11063-9216

NUT;HEX. M12X1.5

desc: ECROU

6шт.

23

65.08120-0017

SCREEN;HEAT

desc: ECRAN THERMIQUE

1шт.

24

06.08092-2408

SCREW;PLUG M26X1.5

desc: VIS

1шт.

25

06.56190-0728

RING;SEAL A26X32

desc: BAGUE

1шт.

26

06.01933-3218

HEX. BOLT ASS'Y

desc: BOULON A 6 PANS

10шт.
