Запчасти Doosan Daewoo SEAT & ELECTRIC BOX BODY PARTS

-

2195-3785

CONTROL STAND

SERIAL: 1-1420

-2шт.

-

2197-1504

CONTROL STAND

SERIAL: 1421

-2шт.

1

2901-9021

SEAT ASS'Y

SERIAL: 1-5

1шт.

1

2901-1053B

SEAT ASS'Y

SERIAL: 6-120

1шт.

1

2901-1053C

SEAT ASS'Y

SERIAL: 121-335

1шт.

1

2901-1053E

SEAT ASS'Y

SERIAL: 336

1шт.

1

2901-1053G

SEAT ASS'Y

desc: ENSEMBLE SIEGE

1шт.

1

2901-1053H

SEAT ASS'Y

desc: ENSEMBLE SIEGE

1шт.

1

2901-1081

SEAT ASS'Y

SERIAL: 1421-2110

1шт.

1

2901-1081A

SEAT ASS'Y

SERIAL: 2111

1шт.

1

1.901-00003

SEAT ASS'Y

desc: ENSEMBLE SIEGE

1шт.

1-1

2901-9034A

SEAT

desc: . SIEGE

1шт.

1-2

1.195-00021

PLATE;SEAT

desc: . PLAQUE

1шт.

1-3

S2209061

BOLT;SOCKET M8X1.25X25

desc: . BOULON ON DE PLOT

4шт.

3

2512-1085G

BOX;ELECTRIC

desc: BOITE ELECTRIQUE

1шт.

3-1

2512-1084A

BOX;ELECTRIC

SERIAL: 1-55

1шт.

3-1

2512-1084B

BOX;ELECTRIC

SERIAL: 56-190

1шт.

3-1

2512-1084C

BOX;ELECTRIC

SERIAL: 191

1шт.

3-2

2621-2665B

COVER

SERIAL: 1-190

1шт.

3-2

2621-2665C

COVER

SERIAL: 191

1шт.

3-3

2621-2666

COVER

SERIAL: 1-5

1шт.

3-3

2621-2775

COVER

SERIAL: 6-120

1шт.

3-3

2621-2775A

COVER

SERIAL: 121

1шт.

3-4

2621-2667

COVER

desc: . COUVERCLE

1шт.

3-5

2621-2668

COVER

desc: . COUVERCLE

1шт.

3-6

2621-2669

COVER

desc: . COUVERCLE

1шт.

3-7

2621-2670A

COVER

desc: . COUVERCLE

1шт.

3-8

2621-2671A

COVER

desc: . COUVERCLE

1шт.

3-9

S0511953

BOLT M10X1.5X22

desc: . BOULON A 6 PANS

4шт.

3-10

S0504453

BOLT M6X1.0X12

desc: . BOULON A 6 PANS

12шт.

3-11

S3450823

SCREW M5X0.8X10

desc: . VIS

4шт.

3-12

S0504453

BOLT M6X1.0X12

desc: . BOULON A 6 PANS

5шт.

3-13

S5102603

WASHER;SPRING M6

desc: . RONDELLE ELASTIQUE

4шт.

3-14

S5010613

WASHER;PLAIN M6

desc: . RONDELLE PLATE

4шт.

3-15

S5102303

WASHER;SPRING M6

desc: . RONDELLE ELASTIQUE

17шт.

3-16

S5010313

WASHER;PLAIN M6

desc: . RONDELLE PLATE

17шт.

3-17

S5100203

WASHER;SPRING M5

desc: . RONDELLE ELASTIQUE

4шт.

3-18

S5000213

WASHER;PLAIN M5

desc: . RONDELLE PLATE

4шт.

3-19

2512-1085-19

CUSHION;RUBBER

desc: . COUSSIN CAOUTCHOUC

2шт.

16

S0515153

BOLT M12X1.75X28

desc: BOULON A 6 PANS

4шт.

17

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

18

S5010713

WASHER;PLAIN M12

desc: RONDELLE PLATE

4шт.

20

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

21

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

4шт.

24

S5000113

WASHER;PLAIN M4

desc: RONDELLE ELASTIQUE

2шт.

35

S0508753

BOLT M8X1.25X18

desc: BOULON A 6 PANS

4шт.

36

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

4шт.

37

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

40

S3458583

SCREW M4X0.7X12

desc: VIS

2шт.

73

2133-1835

LEVER;TRAVEL(R.H)

SERIAL: 1-400

1шт.

73

2133-1967

LEVER;TRAVEL(R.H)

SERIAL: 401-1230

1шт.

73

2133-1967A

LEVER;TRAVEL(R.H)

SERIAL: 1231

1шт.

74

2133-1836

LEVER;TRAVEL(L.H)

SERIAL: 1-400

1шт.

74

2133-1968

LEVER;TRAVEL(L.H)

SERIAL: 401-1230

1шт.

74

2133-1968A

LEVER;TRAVEL(L.H)

SERIAL: 1231

1шт.

75

S0512453

BOLT M10X1.5X10

desc: BOULON A 6 PANS

4шт.

76

2132-1104B

KNOB

SERIAL: 1-55

2шт.

76

2133-1927

LEVER;LOWER

SERIAL: 56

2шт.

77

S3454993

SCREW M6X1.0X25

desc: VIS

2шт.

78

2133-1928

LEVER;UPPER

SERIAL: 56

2шт.
