Запчасти Doosan Daewoo INSTRUMENT PANEL COVER BODY PARTS

-

2195-3785

CONTROL STAND ASS'Y

SERIAL: 1-1420

-2шт.

-

2197-1504

CONTROL STAND ASS'Y

SERIAL: 1421

-2шт.

4

2195-3680

BRACKET

SERIAL: 1-25

1шт.

4

2195-3680A

BRACKET

SERIAL: 26

1шт.

5

2621-2679

COVER;BRACKET(L.H)

SERIAL: 1-400

1шт.

5

2621-2679A

COVER;BRACKET(L.H)

SERIAL: 401

1шт.

6

2621-2678

COVER;BRACKET(R.H)

desc: COUVERCLE

1шт.

19

S0511852

BOLT M10X1.5X20

SERIAL: 1-400

4шт.

19

S0511853

BOLT M10X1.5X20

SERIAL: 401

4шт.

20

S5102601

WASHER;SPRING M10

SERIAL: 1-400

4шт.

20

S5102603

WASHER;SPRING M10

SERIAL: 401

4шт.

21

S5010611

WASHER;PLAIN M10

SERIAL: 1-400

4шт.

21

S5010613

WASHER;PLAIN M10

SERIAL: 401

4шт.

23

S3450571

SCREW M4X0.7X10

SERIAL: 1-400

2шт.

23

S3450573

SCREW M4X0.7X10

SERIAL: 401

2шт.

24

S5000111

WASHER;PLAIN M4

SERIAL: 1-400

2шт.

24

S5000113

WASHER;PLAIN M4

SERIAL: 401

2шт.

25

S3458842

SCREW M5X0.8X14

SERIAL: 1-400

12шт.

25

S3458843

SCREW M5X0.8X14

SERIAL: 401

12шт.

26

S5000211

WASHER;PLAIN M5

SERIAL: 1-400

12шт.

26

S5000213

WASHER;PLAIN M5

SERIAL: 401

12шт.

27

S5102201

WASHER;SPRING M5

SERIAL: 1-400

12шт.

27

S5102203

WASHER;SPRING M5

SERIAL: 401

12шт.

28

2906-9004

ASH TRAY

desc: CENDRIER

1шт.

40

S2201662

BOLT;SPOCKET M4X0.7X12

SERIAL: 1-400

1шт.

40

S3458583

SCREW M4X0.7X12

SERIAL: 401

1шт.

41

S5102101

WASHER;SPRING M4

SERIAL: 1-400

4шт.

41

S5102103

WASHER;SPRING M4

SERIAL: 401

4шт.

43

2621-2738

COVER(LOWER)

desc: COUVERCLE

1шт.
