Запчасти Doosan Daewoo PEDAL VALVE HYDRAULIC PARTS

-

420-00030

PEDAL VALVE

desc: VANNE

1шт.

1

423-00046

BODY(1)

desc: BOITIER

1шт.

2

423-00047

BODY(2)

desc: BOITIER

1шт.

3

181-00318

PLUG NPT1/16

desc: BOUCHON

4шт.

4

2181-1116D3

PLUG PT3/8

desc: BOUCHON

2шт.

5

429-00004

SEAT;SPRING

desc: RESSORT DE SIEGE

4шт.

6

129-00041

SPRING

desc: RESSORT

4шт.

7

429-00005

SEAT;SPRING

desc: RESSORT DE SIEGE

4шт.

8

424-00042

SPOOL

desc: BOBINE

4шт.

9

161-00080

STOPPER

desc: TAQUET D'ARRET

4шт.

10

129-00042

SPRING

desc: RESSORT

4шт.

11

429-00006

GUIDE;ROD

desc: GUIDE

4шт.

12

S8000221

O-RING

desc: JOINT TORIQUE

4шт.

13

115-00041

RING;SNAP

desc: BAGUE

4шт.

14

454-00006

ROD;PUSH

desc: TIGE DE POUSSOIR

4шт.

15

S5740470

PIN;SPRING

desc: BROCHE

4шт.

16

180-00197

SEAL

desc: JOINT D'HUILE

4шт.

17

148-00012

BALL;STEEL

desc: BILLE

4шт.

18

129-00043

SPRING

desc: RESSORT

4шт.

19

159-00017

PLATE

desc: PLAQUE

4шт.

20

115-00042

RING;SNAP

desc: BAGUE

4шт.

21

181-00319

PLUG

desc: BOUCHON

4шт.

22

S8010251

O-RING

desc: JOINT TORIQUE

4шт.

23

180-00198

SEAL;ROD

desc: TIGE D'ETANCHEITE

4шт.

24

180-00199

SEAL;DUST

desc: PARE-POUSSIERES

4шт.

25

442-00001

COVER

desc: COUVERCLE

2шт.

26

S2205261

BOLT;WRENCH M6X1.0X30

desc: BOULON A 6 PANS CREUX

4шт.

27

354-00002

CAM

desc: CAME

2шт.

28

2110-1184D7

BUSHING

desc: MANCHON

4шт.

29

354-00003

SHAFT;CAM

desc: ARBRE A CAMES

2шт.

30

120-00126

SCREW;SET

desc: VIS

2шт.

31

120-00127

SCREW;SET

desc: VIS

4шт.

32

S4014633

NUT M10

desc: ECROU

4шт.

33

160-00008

BELLOWS

desc: SOUFFLET

2шт.

34

114-00225

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

35

S8000121

O-RING

desc: JOINT TORIQUE

4шт.

36

S8000101

O-RING

desc: JOINT TORIQUE

2шт.

37

S2212461

BOLT;WRENCH M10X1.5X42

desc: BOULON A 6 PANS CREUX

4шт.
