Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

1

65.03101-6071B

CYLINDER HEAD ASS'Y

desc: ENSEMBLE CULASSE

1шт.

2

65.03101-1043C

HEAD;CYLINDER

SC: D

1шт.

3

65.03203-1053

SEAT;INLET VALVE

desc: . SIEGE

6шт.

4

65.03203-1054

SEAT;EXHAUST VALVE

desc: . SIEGE

6шт.

5

65.03201-1013A

GUIDE;VALVE

desc: . GUIDE-SOUPAPE

12шт.

6

65.90302-0045

PLUG;CORE

desc: . BOUCHON B28D

3шт.

7

65.90302-0019B

PLUG;CORE

desc: . BOUCHON B28D

11шт.

8

65.90302-0015

PLUG;CORE

desc: . BOUCHON B28D

1шт.

9

65.90302-0027

PLUG;CORE

desc: . BOUCHON B28D

6шт.

10

65.90302-0011

PLUG;CORE

desc: . BOUCHON B28D

6шт.

11

65.90302-0030

PLUG;CORE

desc: . BOUCHON B28D

6шт.

21

65.90302-0017

PLUG;WATER JET CORE

desc: BOUCHON

6шт.

22

65.91710-0004

RING;STOPPER

desc: BAGUE

2шт.

23

65.90021-0002

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

18шт.

24

65.90021-0003

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

6шт.

25

65.90021-0004

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

2шт.

26

06.06125-8717

BOLT;STUD

desc: BOULON DE GOUJON

9шт.

27

06.06125-8723

BOLT;STUD

desc: BOULON DE GOUJON

2шт.

28

06.06125-8709

BOLT;STUD

desc: BOULON DE GOUJON

1шт.

29

06.06225-0706

BOLT;STUD

desc: BOULON DE GOUJON

3шт.

31

65.03901-0055

GASKET;CYLINDER HEAD

desc: JOINT

1шт.

32

65.26815-0002

PLUG

desc: BOUCHON

6шт.

33

65.19202-5005

HOOK;LIFTING

desc: CROCHET

1шт.

34

06.01733-4409

BOLT;HEX M14X1.5X25

desc: BOULON A 6 PANS

1шт.

35

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

36

06.01733-4208

BOLT M10X1.25X22

desc: BOULON A 6 PANS

1шт.

37

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

38

65.19202-0005

HOOK;LIFTING

desc: CROCHET

1шт.

39

06.01943-3213

BOLT ASS'Y M10X1.25X20

desc: BOULON A 6 PANS

2шт.

41

65.03401-6097

CYLINDER HEAD COVER ASS'Y

desc: COUVRE-CULASSE

1шт.

42

65.03401-6094

CYLINDER HEAD COVER

desc: . COUVRE-CULASSE

1шт.

43

65.03903-0001

PACKING;COVER

desc: . EMBALLAGE

1шт.

44

65.01801-0011

CASE;BREATHER

desc: . BOITE

1шт.

45

06.04190-8808

BOLT M5X16

desc: . BOULON A 6 PANS

6шт.

46

06.16731-2104

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

6шт.

47

65.03905-0002B

GASKET;HEAD COVER

desc: . JOINT

1шт.

48

65.03905-0023A

GASKET;HEAD COVER

desc: JOINT

4шт.

49

65.90501-0028

NUT;HEAD COVER

desc: ECROU

4шт.

50

65.90701-0202

WASHER;PLATE

desc: RONDELLE

4шт.

61

65.01801-5035A

BREATHER PIPE ASS'Y

desc: CLAPET DE RECHANGE

1шт.

62

65.96501-0032B

O-RING

desc: JOINT TORIQUE

1шт.

63

65.96301-0417

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

64

65.97401-0179

CLIP;WATER HOSE

desc: CLIP

2шт.

65

06.67020-0105

CLAMP

desc: ATTACHE DE TUYAU

1шт.

66

06.11063-8214

NUT;HEX M8

desc: ECROU

1шт.

67

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

68

06.01913-3111

BOLT ASS'Y M8X16

desc: BOULON A 6 PANS

1шт.

71

65.01810-5011

OIL FILLER CAP ASS'Y

desc: VIBREUR

1шт.
