1
65.01101-6051L
CYLINDER BLOCK ASS'Y
desc: BLOC CYLINDRE
1шт.
2
65.01101-0030I
BLOCK;CYLINDER
SC: D
1шт.
3
65.01105-1044A
CAP;BEARING(F.M.R)
SC: D
6шт.
5
65.01105-1043A
CAP;BEARING(NO.4)
SC: D
1шт.
7
65.91710-0001
RING;STOPPER
desc: . BAGUE D'ETANCHEITE
2шт.
8
65.90020-0066A
BOLT;HEX
desc: . BOULON A 6 PANS
14шт.
9
65.04410-0007D
BUSH;CAM SHAFT
SC: B
1шт.
10
65.04410-0006C
BUSH;CAM SHAFT
SC: B
5шт.
11
65.90302-0009
PLUG;CORE
desc: . BOUCHON B28D
2шт.
12
65.90302-0041
PLUG;CORE
desc: . BOUCHON B28D
2шт.
13
65.90302-0042
PLUG;CORE
desc: . BOUCHON B28D
3шт.
15
65.90310-0030
SCREW;PLUG M12X1.25
desc: VIS
1шт.
16
06.56190-0704
RING;SEAL A12X18
desc: BAGUE D'ETANCHEITE
1шт.
17
65.90320-0019
SCREW;PLUG PT3/8
desc: VIS
1шт.
18
06.15091-0313
PLUG;CORE
desc: BOUCHON
2шт.
19
65.90320-0022
SCREW;PLUG PT1/8
desc: VIS DE REGLAGE
10шт.
20
65.90201-0058
BOLT;STUD M14X12.5X45
desc: BOULON DE GOUJON
1шт.
21
65.91605-0001E
COVER
desc: COUVERCLE
1шт.
22
06.01913-3113
BOLT ASS'Y M8X20
desc: BOULON A 6 PANS
2шт.
23
65.01112-0021A
COVER;PUSH ROD CHAMBER
desc: COUVERCLE
2шт.
24
65.01112-5018
COVER;PUSH ROD CHAMBER
desc: COUVERCLE
1шт.
25
65.90020-0049
BOLT;HEX
desc: BOULON A 6 PANS
6шт.
26
65.96507-0007
PACKING;JOINT
desc: EMBALLAGE
6шт.
27
65.01110-6090B
METAL;CRANK STD
desc: COUSSINET
7шт.
27
65.01110-6091B
METAL;CRANK 0.25
SC: US
7шт.
27
65.01110-6092B
METAL;CRANK 0.50
SC: US
7шт.
28
65.01150-6008
WASHER;THRUST STD
desc: RONDELLE
2шт.
29
65.91615-0011
COVER;BLIND
desc: COUVERCLE
1шт.
30
06.01913-3113
BOLT ASS'Y
desc: BOULON A 6 PANS
2шт.
31
65.01201-0067
LINER;CYLINDER (ALTV.)
SC: D
6шт.
31
65.01201-0068
LINER;CYLINDER(1A)
desc: CHEMISE DE CYLINDRE
6шт.
31
65.01201-0069
LINER;CYLINDER(1B)
desc: CHEMISE DE CYLINDRE
6шт.
31
65.01201-0070
LINER;CYLINDER(2A)
desc: CHEMISE DE CYLINDRE
6шт.
31
65.01201-0071
LINER;CYLINDER(2B)
desc: CHEMISE DE CYLINDRE
6шт.
36
65.01901-0020
GASKET;CHAMBER COVER
desc: JOINT
3шт.
37
06.56021-0106
O-RING G50
desc: JOINT TORIQUE
1шт.
38
65.90310-0135
SCREW;PLUG M14X1.5
desc: BOUCHON A VIS
1шт.
39
06.56190-0706
RING;SEAL A14X20
desc: BAGUE D'ETANCHEITE
1шт.
40
65.05903A0013
GASKET
desc: JOINT
1шт.
41
65.90310-0122
SCREW;PLUG
desc: VIS
1шт.
42
06.56190-0713
RING;SEAL A18X24
desc: BAGUE D'ETANCHEITE
1шт.
43
65.01601-5010A
OIL JET PIPE
desc: REFROIDISSEUR D'HUILE
6шт.
44
65.05401-5023
RELIEF VALVE ASS'Y
desc: COUVERCLE ETANCHE
6шт.
45
06.56021-0102
O-RING G30
desc: JOINT TORIQUE
1шт.
46
65.05401-5002F
RELIEF VALVE ASS'Y
desc: COUVERCLE ETANCHE
1шт.
47
65.27441-7006
SWITCH;OIL PRESS
desc: INTERRUPTEUR
1шт.
48
65.90201-0182
BOLT;STUD
desc: BOULON DE GOUJON
1шт.
