Запчасти Doosan Daewoo MAIN PIPING-PE3C OPTION PARTS

-

K1005252F1

MAIN PIPING-PE3C

SC: D

-2шт.

1

2420-9627B

VALVE;RELIEF

desc: VANNE

1шт.

2

K1002695

VALVE;SWITCH

desc: VANNE

1шт.

3

2181-2614

BLOCK;SPACER

desc: BLOC

1шт.

4

K1005201

BRACKET;L.H

desc: SUPPORT

1шт.

5

K1005202

BRACKET;R.H

desc: SUPPORT

1шт.

6

DS2018099

HOSE

desc: TUYAU FLEXIBLE

1шт.

7

DS2013594

HOSE

desc: TUYAU FLEXIBLE

1шт.

8

DS2013595

HOSE

desc: TUYAU FLEXIBLE

1шт.

9

2184-1200D52

HOSE

desc: TUYAU FLEXIBLE

1шт.

10

DS2012180

HOSE

desc: TUYAU FLEXIBLE

1шт.

11

DS2021056

HOSE

desc: TUYAU FLEXIBLE

1шт.

12

2181-4133D6

ADAPTER

desc: ADAPTATEUR

5шт.

13

2181-2818

ADAPTER

desc: ADAPTATEUR

1шт.

14

2181-2815D1

ELBOW

desc: COUDE

1шт.

15

2181-2293D4

TEE

desc: TE

1шт.

16

2180-1026D19

O-RING

desc: JOINT TORIQUE

3шт.

17

S8000291

O-RING

desc: JOINT TORIQUE

9шт.

18

S8030161

O-RING

desc: JOINT TORIQUE

8шт.

19

2181-9083

FLANGE;SPLIT

desc: BRIDE

4шт.

20

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON DE PLOT

4шт.

21

S2215766

BOLT;SOCKET M12X1.75X55

desc: BOULON DE PLOT

4шт.

22

S2213066

BOLT;SOCKET M10X1.5X70

desc: BOULON DE PLOT

4шт.

23

S5010713

WASHER;PLAIN

desc: RONDELLE PLATE

2шт.

24

S0559153

BOLT M10X1.5X80

desc: BOULON A 6 PANS

2шт.

25

S0515453

BOLT M12X1.75X40

desc: BOULON A 6 PANS

4шт.

26

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

27

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

2шт.

28

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

29

124-00316A

CLAMP;HOSE

desc: FIXATION DE TUYAU

2шт.

30

621-03028

PLATE

desc: PLAQUE

1шт.

31

621-03029

PLATE

desc: PLAQUE

1шт.

32

2182-1018D47

PIPE

desc: TUYAU

2шт.

33

2420-1226

VALVE;OVERLOAD RELIEF

desc: VANNE

2шт.

34

K1005225

VALVE;SWITCH

desc: VANNE

1шт.
