Запчасти Doosan Daewoo FLOOR ASSY-MATERIAL HANDLING OPTION-MATERIAL HANDLING

-

9621-1057

FLOOR ASS'Y

SC: D

-2шт.

1

161-00493

MAT;FLOOR

desc: PLAQUE

1шт.

2

9621-1058

PLATE;FLOOR

desc: PLAQUE

1шт.

3

195-01735

BRACKET;PEDAL

desc: SUPPORT

1шт.

4

621-01507

PLATE;FLOOR

desc: PLAQUE

1шт.

5

161-00386

RUBBER;PEDAL

desc: CAOUTCHOUC

1шт.

6

195-01939

BRACKET;LOCK

desc: SUPPORT

1шт.

7

2114-1898D1

WASHER

desc: RONDELLE

4шт.

8

2120-2166D5

BOLT

desc: BOULON

4шт.

9

2114-1898D14

WASHER

desc: RONDELLE

4шт.

10

S2211866

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

11

S5110601

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

12

160-00045

BUSHING;RUBBER

desc: GARNISSAGE CAOUTCHOUC

1шт.

13

S0511653

BOLT

desc: BOULON

4шт.

14

195-02333

REST;FOOT

desc: REPOS DE PIED

1шт.
