Запчасти Doosan Daewoo SWING DEVICE BODY PARTS

-

2401-1255A

SWING DEVICE ASS'Y

SERIAL: 1001-1814

-2шт.

-

2401-1255B

SWING DEVICE ASS'Y

SERIAL: 1815

-2шт.

1

401-00051B

SWING DEVICE SUB ASS'Y

SERIAL: 1001-1378

1шт.

1

401-00051C

SWING DEVICE SUB ASS'Y

SERIAL: 1379-1742

1шт.

1

401-00051E

SWING DEVICE SUB ASS'Y

SERIAL: 1743-1814

1шт.

1

401-00051G

SWING DEVICE SUB ASS'Y

SERIAL: 1815

1шт.

1A

401-00086A

MOTOR;SWING

SERIAL: 1001-1814

1шт.

1A

401-00086B

MOTOR;SWING

SERIAL: 1815

1шт.

1B

2404-1063J

REDUCTION GEAR ASS'Y

SERIAL: 1001-1742

1шт.

1B

K1004160A

REDUCTION GEAR ASS'Y

SERIAL: 1743

1шт.

1C

2181-1113D2

REDUCER PT1/2-PT3/8

desc: . REDUCTEUR

1шт.

1D

186-00013

COCK

desc: . ROBINET

1шт.

1E

2181-1913D24

REDUCER PT1/2-PT3/4

desc: . REDUCEUR

1шт.

1F

2182-1662

PIPE

desc: . CONDUITE

1шт.

1G

2119-1063A

CAP;PIPE

desc: . CHAPEAU

1шт.

1H

S8450012

CLAMP;HOSE

desc: . COLLIER

1шт.

1I

184-00016

HOSE

desc: . TUYAU FLEXIBLE

1шт.

2

S0570166

BOLT M20X2.5X65

desc: BOULON A 6 PANS

11шт.

3

2114-9012A

WASHER;HARDEN

desc: RONDELLE

11шт.

4

2123-4030

PIN;LOCK

desc: GOUPILLE

1шт.
