Запчасти Doosan Daewoo REMOTE CONTROL VALVE-DOZER PILOT PIPING(6)

-

420-00377

REMOTE CONTROL VALVE-DOZER

desc: VANNE DE COMMAND A DISTANCE

1шт.

1

J96H2001

BODY

desc: CARROSSERIE

1шт.

2

J96H2002

PLUG

desc: BOUCHON

2шт.

3

P008

O-RING P8

desc: JOINT TORIQUE

2шт.

4

J96H2003

SPRING

desc: RESSORT

2шт.

5

AJV12D105

SEAT;SPRING

desc: SIEGE DE RESSORT

2шт.

6

J96H2004

SPOOL

desc: BOBINE

2шт.

7

AJV12D103

SEAT;SPRING

desc: SIEGE DE RESSORT

2шт.

8

J96H2005

SPRING

desc: RESSORT

2шт.

9

AJV12D106

STOPPER

desc: ARRET

2шт.

10

J96H2006

PLUG

desc: BOUCHON

2шт.

11

RSY10

SEAL DYR10

desc: TIGE D'ETANCHEITE

2шт.

12

P0014

O-RING P12

desc: JOINT TORIQUE

2шт.

13

J96H2007

ROD;PUSH

desc: TIGE

2шт.

14

J96H2008

COVER

desc: COUVERCLE

1шт.

15

WBM0635

BOLT;WRENCH M6X35

desc: BOULON A 6 PANS

2шт.

16

J96H2009

GUIDE

desc: GUIDE

1шт.

17

J96H2010

PIN

desc: BROUCHE

1шт.

18

J96H2011

BOLT M5X15

desc: BOULON A 6 PANS

2шт.

19

HNM05

NUT M5

desc: ECROU

2шт.

20

JA2C1001

LEVER

desc: LEVIER

1шт.

21

SP0318

PIN;SPRING

desc: BROUCHE

1шт.

22

J96H2013

BOOT

desc: GAINE DE PROTECTION

1шт.

23

JA2C1002

BUSHING

desc: MANCHON

1шт.

24

SR09E

RING;SNAP

desc: BAGUE ELASTIQUE

1шт.
