Запчасти Doosan Daewoo SWING REDUCTION GEAR SWING DEVICE

-

2404-1063J

GEAR;REDUCTION

desc: REDEUTEUR

1шт.

1

2423-1496G

CASING

SC: D

1шт.

2

2112-1248C

SHAFT;DRIVE

desc: AXE

1шт.

3

2412-1040

PLATE

desc: RONDELLE

1шт.

4

2109-9033

BEARING;ROLLER

desc: ROULEMENT A BILLES

1шт.

5

2891-1421B

PLATE;COVER

desc: PLAQUE

1шт.

7

2180-1254

SEAL;OIL

desc: JOINT D'HUILE

1шт.

8

109-00174

BEARING;ROLLER

desc: ROULEMENT A BILLES

1шт.

9

2104-1013A

GEAR;RING

desc: PIGNON

1шт.

10

2230-1037A

CARRIER NO.2

desc: SUPPORT

1шт.

11

2114-1901A

WASHER;THRUST NO.2

desc: RONDELLE

8шт.

12

2104-1022B

GEAR;PLANET NO.2

desc: PIGNON

4шт.

13

2110-1371A

BUSH NO.2

desc: MANCHON

4шт.

14

2123-2322B

PIN NO.2

desc: GOUJON

4шт.

15

S5741341

PIN;SPRING

desc: GOUPILLE FENDUE

4шт.

16

S0121061

BOLT M16X25

desc: BOULONE A 6 PANS

1шт.

17

2114-1902

WASHER;THRUST NO.3

desc: RONDELLE

1шт.

18

2104-1021B

GEAR;SUN NO.2

desc: PIGNON

1шт.

19

2705-1030

PIN;KNOCK

desc: BROCHE DE BLOCAGE

4шт.

20

2230-1036B

CARRIER NO.1

desc: SUPPORT

1шт.

22

2104-1020C

GEAR;PLANET NO.1

desc: PIGNON

4шт.

23

2123-2327A

PIN ASS'Y NO.1

desc: GOUJON

4шт.

24

S2217471

BOLT;SOCKET M12X150

desc: BOULON A 6 PANS CREUX

16шт.

25

2104-1019B

GEAR;SUN NO.1

desc: PIGNON

1шт.

26

S6500450

RING;SNAP

desc: BAGUE D'ARRET

1шт.

27

2181-1116D2

PLUG PT1/4

desc: BOUCHON

2шт.

28

2181-1116D4

PLUG PT1/2

desc: BOUCHON

1шт.

29

2140-1406

PIPE;LEVEL GAUGE

desc: TUYAU

1шт.

30

2119-1065

LEVEL GAUGE

desc: JAUGE DE NIVEAU

1шт.

31

S5231090

WASHER;DOUBLE TAP

desc: RONDELLE

1шт.

32

2182-1756A

PIPE

desc: TUYAU

4шт.

33

120-00144

BOLT;HEX. M10X1.5X25

desc: BOULON A 6 PANS

8шт.

50

230-00050

CARRIER NO.1 ASS'Y

desc: ENSEMBLE SUPPORT

1шт.

51

230-00051

CARRIER NO.2 ASS'Y

desc: ENSEMBLE SUPPORT

1шт.
