Запчасти Doosan Daewoo STEERING COLUMN ASSY BODY PARTS

-

303-00003

STEERING COLUMN ASS'Y

desc: COLONNE DE DIRECTION

1шт.

2

2.621-00004

TUBE;COMPLETE UPPER

desc: TUYAU FLEXIBLE

2шт.

3

2.621-00005

TUBE;COMPLETE UPPER

desc: TUYAU FLEXIBLE

2шт.

4

2.123-00301

PIN;TILT REGISTRY COMPLETE

desc: GOUJON

2шт.

5

2.114-01347

SPACER

desc: BAGUE

2шт.

6

2.133-00001

LEVER;HANDLE

desc: LEVIER

2шт.

7

2.115-00213

RING;SEEGER

desc: BAGUE DE SOUTIEN

2шт.

8

2.405-00241

SHAFT;TOP SUBASSEMBLE

desc: ARBRE

2шт.

9

2.713-00002

TOOTH

desc: DENT

2шт.

10

2.120-00847

SCREW

desc: VIS

2шт.

11

2.197-00071

SUPPORT;JOINT

desc: APPUI

2шт.

12

2.120-00848

SCREW

desc: VIS

2шт.

13

2.114-01348

SHIM 0.5mm

desc: CALE

2шт.

14

2.114-01349

SHIM 1.0mm

desc: CALE

2шт.

15

2.621-00006

CASE;ABS UPPER

desc: COUVERCLE

2шт.

16

2.160-00016

BELLOWS

desc: SOUFFLET

2шт.

17

2.114-01350

WASHER

desc: RONDELLE

2шт.

18

2.120-00849

SCREW M6x16

desc: VIS

2шт.

19

2.160-00017

TUBE;PROTECTION

desc: TUYAU FLEXIBLE

2шт.

20

2.198-00003

RUBBER;PROTECTION

desc: CAOUTCHOUC

2шт.

21

2.114-00124

SHIM

desc: CALE

2шт.

22

2.121-00058

NUT

desc: ECROU

2шт.

23

2.121-00264

NUT;SELFLOCKING M5

desc: ECROU

2шт.

24

2.180-01228

O-RING 108-612

desc: JOINT TORIQUE

2шт.
