Запчасти Doosan Daewoo MAIN PIPING(4)-SWING BODY PARTS

-

2400-1934A

MAIN PIPING

SC: D

-2шт.

10

2184-1124D78

HOSE PF3/4-530L

desc: TUYAU FLEXIBLE

1шт.

11

2184-1124D158

HOSE PF3/4-620L

desc: TUYAU FLEXIBLE

1шт.

28

S2212261

BOLT;SOCKET M10X1.5X30

SERIAL: 1001-1310

8шт.

28

S2212266

BOLT;SOCKET M10X1.5X30

SERIAL: 1311

8шт.

33

2180-1026D2

O-RING

desc: JOINT TORIQUE

4шт.

34

2181-9079

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

8шт.

44

S2213061

BOLT;SOCKET M10X1.5X70

SERIAL: 1001-1310

8шт.

44

S2213066

BOLT;SOCKET M10X1.5X70

SERIAL: 1311

8шт.

50

2181-1126D25

ADAPTER PFO1-PF1

desc: RACCORD ADAPTATEUR

1шт.

51

2181-1126D97

ADAPTER PFO1-PF1

desc: RACCORD ADAPTATEUR

1шт.

52

S8000291

O-RING

desc: JOINT TORIQUE

2шт.

53

2184-1061D265

HOSE PF1-850L

desc: TUYAU FLEXIBLE

1шт.
