Запчасти Doosan Daewoo STEERING VALVE STEERING ASSY

-

2420-9551

VALVE;STEER

desc: VANNE DE DIRECTION

1шт.

1

633B9002

DUST;SEAL

desc: BAGUE

1шт.

2

-

HOUSING

SC: D

1шт.

3

689X1031

BALL

desc: BILLE

1шт.

4

150-0304

THREAD BUSHING

desc: MANCHON

1шт.

5

150N4014

O-RING

desc: JOINT TORIQUE

1шт.

7

150-4262

BEARING

desc: PALIER

1шт.

8

150-0310

RING;BACK UP

desc: BAGUE DE SOUTIEN

1шт.

9

150-0305

CROSS PIN

desc: BROCHE

1шт.

11

150-0844

CARDAN SHAFT

desc: TOURNEVIS EN CROIX

1шт.

12

150N4035

SPRING

desc: RESSORT

1шт.

13

633B1202

O-RING

desc: JOINT TORIQUE

1шт.

14

150N0610

DISTRIBUTOR PLATE

desc: PLAQUE

1шт.

15

150-4188

GEAR;WHEEL

desc: PIGNON

1шт.

16

633B1173

O-RING

desc: JOINT TORIQUE

2шт.

17

150-0328

END;COVER

desc: COUVERCLE

1шт.

18

684X2481

WASHER

desc: RONDELLE

7шт.

20

150-0325

SCREW

desc: VIS

1шт.

21

681X1582

SCREW

desc: VIS

6шт.

24

150-4270

RELIEF VALVE

desc: VANNE

1шт.

25

663X1802

SPRING

desc: RESSORT

1шт.

26

150-4268

SHOCK VALVE

desc: VANNE

2шт.

27

689X1005

BALL

desc: BILLE

2шт.

29

150-4080

BUSHING

desc: BROCHE

2шт.

32

150N4092

CHECK VALVE

desc: VANNE

1шт.

*

150N4038

SEAL KIT

SC: S

1шт.
