Запчасти Doosan Daewoo OUTRIGGER PIPING-FRONT TRACK PARTS

-

2400-4206

FRONT OUTRIGGER PIPING

desc: HYDRAULIQUE PORTANT-DEHORS FORNTALE

-2шт.

1

S8000111

O-RING P11

REP_PNO: 8202-009

3шт.

2

2181-1126D14

ADAPTER PFO. PF1/4

desc: RACCORD

2шт.

3

2184-1061D2

HOSE PF1/4-1235L

desc: TUYAU FLEXIBLE

1шт.

4

2181-1702D3

ELBOW PF1/4. 3/8

desc: RACCORD

1шт.

5

2184-1036D181

HOSE PF3/8-1200L

desc: TUYAU FLEXIBLE

1шт.

6

2420-9291

VALVE;SELECTOR

desc: VANNE DE SELECTION

1шт.

7

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

3шт.

8

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

3шт.

9

S2213161

BOLT;SOCKET M10X1.5X75

desc: BOULON A 6 PANS CREUX

3шт.

10

S8000241

O-RING P24

desc: JOINT TORIQUE

1шт.

11

2181-1126D24

ADAPTER;S PF1/2. 3/4

desc: RACCORD

1шт.

12

2184-1026D104

HOSE PF1/2-550L

desc: TUYAU FLEXIBLE

1шт.

13

S8000181

O-RING P18

REP_PNO: 8202-014

5шт.

14

2181-1126D6

ADAPTER PFO. PF1/2

desc: RACCORD

5шт.

15

2184-1026D317

HOSE PF1/2-1650L

desc: TUYAU FLEXIBLE

1шт.

16

2184-1026D309

HOSE PF1/2-950L

SERIAL: 1-300

4шт.

16

2184-1026D309

HOSE PF1/2-950L

SERIAL: 301

3шт.

17

2158-1003D4

PROTECTOR;HOSE

desc: PROTECTEUR

4шт.

18

2183-4810

PIPE

SERIAL: 9

1шт.

19

2183-4809

PIPE

SERIAL: 9

1шт.

20

2124-1340D5

CLAMP;PIPE

desc: ATTACHE DE TUYAU

2шт.

21

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

2шт.

22

S0560653

BOLT M12X1.75X45

desc: BOULON A 6 PANS

2шт.

23

2124-1084D3

CLIP;BAND

desc: ATTACHE

2шт.

24

2184-1026D331

HOSE PF1/2-1000L

SERIAL: 301

1шт.
