Запчасти Doosan Daewoo COOLING WATER PUMP ENGINE PARTS

-

65.06500-6134

WATER PUMP ASS'Y

desc: ENSEMBLE POMPE A EAU

1шт.

2

06.01013-9119

BOLT;HEX. M8X70

desc: . BOULON A 6 PANS

2шт.

3

06.16731-2107

WASHER;SPRING A8

desc: . RONDELLE ELASTIQUE

2шт.

5

65.06506-0043

IMPELLAR

SC: D

1шт.

6

65.06520-6007

SEAL;MECHANICAL

SC: D

1шт.

7

65.93410-0027

BEARING;UNIT

SC: D

1шт.

10

06.29020-0132

RING;SNAP 55 X 2

desc: . BAGUE ELASTIQUE

1шт.

11

65.06504-0030

HUB

SC: D

1шт.

12

65.06501-0064A

HOUSING;WATER PUMP

desc: . BOITIER DE POMPE A EAU

1шт.

13

65.06901-0019

GASKET(WATER PUMP. INNER)

desc: . JOINT DE POMPE A EAU(INTERIEUR)

1шт.

14

65.06512-0010

COVER;WATER PUMP

desc: . COUVERCLE DE POMPE A EAU

1шт.

15

06.04201-8907

BOLT;HEAD MACHINE M6X14

desc: . BOULON A 6 PANS

3шт.

19

65.06503-0081

PULLEY;V-BELT

desc: . POULIE DE COURROIE TRAPEZOIDALE

1шт.

20

65.06611-0092

FLANGE

desc: BRIDE

1шт.

21

65.06601-5040

FAN;COOLING(10BLADES)

SERIAL: 970465

1шт.

21

65.06601-5052

FAN;COOLING(9BLADES)

SERIAL: 970466

1шт.

22

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

12шт.

23

06.01013-9123

BOLT;HEX. M8X90

desc: BOULON A 6 PANS

6шт.

28

65.06901-0020

GASKET(WATER PUMP. OUTER)

desc: JOINT DE POMPE A EAU(EXTERIEUR)

1шт.

29

06.01913-3113

BOLT;HEX. M8X40

desc: BOULON A 6 PANS

3шт.

30

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

1шт.

31

06.01013-9219

BOLT;HEX. M10X70

desc: BOULON A 6 PANS

1шт.

32

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

1шт.
