Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

65.01903-0021

GASKET(TIMING GEAR CASE)

desc: JOINT(CARTER DE DISTRIBUTION)

1шт.

2

65.01304-0010

CASE;TIMING GEAR

desc: CARTER DE DISTRIBUTION

1шт.

5

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

1шт.

6

06.01913-3113

BOLT;HEX. M8X20

desc: BOULON A 6 PANS

5шт.

6

06.06225-0704

BOLT;STUD M8X20

desc: GOUJON

1шт.

6

06.11063-8214

NUT;HEX. M8

desc: ECROU

1шт.

8

06.01493-3317

BOLT;HEX. M12X1.5X30

desc: BOULON A 6 PANS

4шт.

9

65.90201-0048

BOLT;STUD

desc: GOUJON

1шт.

10

06.06225-0809

BOLT;STUD M10X35

desc: GOUJON

4шт.

10

06.06225-0810

BOLT;STUD

desc: GOUJON

2шт.

12

65.01903-0113

GASKET(TIMING GEAR CASE COVER)

desc: JOINT(COUVERCLE DE CARTER DE DISTRIBUTIO

1шт.

13

65.01305-5028

TIMING GEAR CASE COVER ASS'Y

desc: ENSEMBLE COUVERCLE DE CARTER DE

1шт.

16

06.01923-2914

BOLT;HEX. M6X22

desc: BOULON A 6 PANS

13шт.

18

65.01903-0029

GASKET(TIMING GEAR CASE COVER)

desc: JOINT(COUVERCLE DE CARTER DE DISTRIBUTIO

1шт.

19

65.01307-5009

TIMING GEAR CASE COVER ASS'Y

desc: ENSEMBLE COUVERCLE DE CARTER DE

1шт.

20

06.15010-2309

WASHER 6.4

desc: RONDELLE PLATE

2шт.

21

06.16731-2105

WASHER;SPRING A6

desc: RONDELLE ELASTIQUE

2шт.

22

06.01923-2918

BOLT;HEX. M6X35

desc: BOULON A 6 PANS

9шт.

23

06.06225-0502

BOLT;STUD M6X16

desc: GOUJON

2шт.

24

06.11063-8212

NUT;HEX. M6

desc: ECROU

2шт.

25

06.22022-0908

PIN;DOWEL 6M6X12

desc: GOUPILLE D'AJUSTAGE 6m6X12

2шт.

26

65.01510-0026

SEAL;CRANK SHAFT(FRONT)

desc: BAGUE D'ETANCHEITE VILEBREQUIN(AVANT)

1шт.

27

65.54903-0013

GASKET

desc: JOINT

1шт.

28

65.54302-5015

BRACKET;AIRCON

desc: SUPPORT

1шт.

29

06.02090-0511

BOLT;SOCKET HEAD

desc: BOULON A 6 PANS CREUX

4шт.

30

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

4шт.

31

65.54306-0010

BRACKET

desc: SUPPORT

1шт.

32

06.01913-3213

BOLT;HEX. M10X1.5X20

desc: BOULON A 6 PANS

2шт.

34

65.95840-0024

BRACKET;IDLE PULLEY

desc: SUPPORT DE POULIE FOU

1шт.

36

06.01913-3213

BOLT;HEX. M10X1.5X20

desc: BOULON A 6 PANS

3шт.

37

65.95800-6014

IDLE PULLEY ASS'Y

desc: ENSEMBLE POULIE FOU

1шт.

38

65.11401-5007

MOUNTING FLANGE ASS'Y

desc: ENSEMBLE BRIDE DE MONTAGE

1шт.

39

65.11902-0018A

GASKET

desc: JOINT

1шт.

40

06.22220-1110

PIN;SPRING

desc: GOUPILLE D'AJUSTAGE 6mX6X20

1шт.

41

06.15010-2312

WASHER;PLATE 10.5

desc: RONDELLE PLATE

7шт.

42

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

7шт.

43

06.11063-8215

NUT;HEX. M10

desc: ECROU

7шт.

44

65.90201-0059

BOLT;STUD M10X35

desc: GOUJON

4шт.

45

65.90310-0033

SCREW;PLUG M10X1.25

desc: BOUCHON A VIS

1шт.

46

06.56180-0714

RING;SEAL A10X15

desc: BAGUE D'ETANCHEITE

1шт.
