Запчасти Doosan Daewoo PISTON ENGINE PARTS

1

65.02501-0074

PISTON

desc: PISTON

6шт.

2

65.02503-0054

RING;TOP

desc: SEGMENT COUP DE FEU

6шт.

3

65.02503-0091

RING;SECOND

SERIAL: 9700012

6шт.

3

65.02503-0120

RING;SECOND

SERIAL: 9700013

6шт.

4

65.02503-0101

RING;OIL

SERIAL: 9700012

6шт.

4

65.02503-0115

RING;OIL

SERIAL: 9700013

6шт.

5

65.02502-0010

PIN;PISTON 42X20X95

desc: AXE DE PISTON

6шт.

6

06.29020-0126

RING;SNAP 42X1.75

desc: CIRCLIP

12шт.

7

65.02401-6101

CONNECTING ROD ASS'Y

desc: ENSEMBLE DE BIELLE

6шт.

8

65.02401-0030

ROD;CONNECTING

desc: . BIELLE

6шт.

9

65.90020-0009

BOLT;CONNECTING ROD

desc: . BOULON A 6 PANS

12шт.

10

65.91301-0010

PIN;DOWEL

desc: . GOUPILLE D'AJUSTAGE 6m6X14

12шт.

11

65.02405-0015B

BUSH;SMALL END

desc: . DOUILLE DU

6шт.

12

65.02410-0010

METAL;CONN. ROD STD

desc: COUSSINET TETE DE BIELLE STD

6шт.

12

65.02410-0011

METAL;CONN. ROD 0.25

SC: US

6шт.

12

65.02410-0012

METAL;CONN. ROD 0.5

SC: US

6шт.

12

65.02410-0013

METAL;CONN. ROD 0.75

SC: US

6шт.

12

65.02410-0014

METAL;CONN. ROD 1.0

SC: US

6шт.
