Запчасти Doosan Daewoo PILOT PIPING(11) BODY PARTS

-

2400-4202

PILOT PIPING

desc: CIRCUIT PILOTE

-2шт.

8

2181-1126D28

ADAPTER PFO. PF3/8

SERIAL: 1-398

1шт.

8

2181-1126D28

ADAPTER PFO. PF3/8

SERIAL: 399

2шт.

9

2181-1126D7

ADAPTER PFO. PF3/8

SERIAL: 1-398

2шт.

9

2181-1126D7

ADAPTER PFO. PF3/8

SERIAL: 399

3шт.

10

S8000141

O-RING P14

REP_PNO: 8202-011

4шт.

11

2181-1126D14

ADAPTER PFO. PF1/4

desc: RACCORD

2шт.

12

S8000111

O-RING P11

REP_PNO: 8202-009

5шт.

24

S0511653

BOLT M10X1.5X16

desc: BOULON A 6 PANS

7шт.

25

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

7шт.

51

2181-1126D34

ADAPTER PFO. PF1/4

desc: RACCORD

2шт.

54

2181-2485

REDUCER

desc: RACCORD

1шт.

55

2549-1135D3

SWITCH;PRESSURE

SERIAL: 1-775

1шт.

55

2549-1135D6

SWITCH;PRESSURE

SERIAL: 776

1шт.

56

S8180161

PACKING

desc: RONDELLE ETANCHE

1шт.

64

2181-1126D27

ADAPTER PFO. PF3/8

desc: RACCORD

2шт.

78

2420-9324A

TRANSMISSION & PILOT SUPPLY VALVE

SERIAL: 1-515

1шт.

78

2420-9324B

TRANSMISSION & PILOT SUPPLY VALVE

SERIAL: 516-530

1шт.

78

2420-9324C

TRANSMISSION & PILOT SUPPLY VALVE

SERIAL: 531

1шт.

81

2195-4831

BRACKET 3/8. 8

desc: SUPPORT

1шт.

82

2184-1096D66

HOSE PF3/8-850L

desc: TUYAU FLEXIBLE

2шт.

109

2184-1046D189

HOSE PF1/4-710L

desc: TUYAU FLEXIBLE

2шт.
