Запчасти Doosan Daewoo MUFFLER BODY PARTS

-

2201-4017

ENGINE ASS'Y

desc: ENSEMBLE MOTEUR

1шт.

28

2195-4833A

BRACKET

SERIAL: 1-576

1шт.

28

2195-4833B

BRACKET

SERIAL: 577

1шт.

29

2203-1056

MUFFLER

SERIAL: 1-95

1шт.

29

2203-1056A

MUFFLER

SERIAL: 96-576

1шт.

29

2203-1056B

MUFFLER

SERIAL: 577

1шт.

30

2182-1082

JOINT;EXPENSION

desc: JOINT DE DILATATION

1шт.

31

2183-3612

PIPE;EXHAUST

desc: TUBULURE D'ECHAPPEMENT

1шт.

32

S0515353

BOLT M12X1.75X35

desc: BOULON A 6 PANS

4шт.

33

S5010713

WASHER;PLAIN M12

desc: RONDELLE PLATE

4шт.

34

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

35

S4012733

NUT M12X1.75

desc: ECROU

4шт.

36

S0512553

BOLT M10X1.5X45

desc: BOULON A 6 PANS

10шт.

37

S4012633

NUT M10X1.5

desc: ECROU

16шт.

38

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

16шт.

39

S0508853

BOLT M8X1.25X20

desc: BOULON A 6 PANS

4шт.

40

2180-1141

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.
