Запчасти Doosan Daewoo ELECTRIC PARTS(6)-BATTERY BODY PARTS

-

2500-1112

ELECTRIC ASS'Y(2)

desc: EQUIPMENT ELECTRIQUE

-2шт.

1

2506-1014

BATTERY 150AH

desc: BATTERIE

2шт.

2

2197-1119

BRACKET;BATTERY

desc: SUPPORT

1шт.

3

2120-1036D8

BOLT M10X1.5X230

SERIAL: 1-95

2шт.

3

2120-1036D12

BOLT M10X1.5X230

SERIAL: 96

2шт.

4

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

5

S5010503

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

16

2544-9024

RELAY;BATTERY

desc: RELAIS BATTERIE

1шт.

17

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

2шт.

18

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

19

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

20

2527-9004

BREAKER;CIRCUIT

desc: COUPE-CIRCUIT

1шт.

21

2120-1354

SCREW

desc: VIS

2шт.

22

2527-1020

LINK;FUSIBLE 27A

desc: LAME DE FUSIBLE

1шт.
