Запчасти Doosan Daewoo AIRCONDITIONER BODY PARTS

-

2920-1044

COMPRESSOR ASS'Y

desc: ENSEMBLE COMPRESSEUR

1шт.

1

2208-6011A

COMPRESSOR ASS'Y(A-TYPE)

SERIAL: 1-170

1шт.

1

2208-6011B

COMPRESSOR ASS'Y(A-TYPE)

SERIAL: 171

1шт.

2

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

2шт.

3

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

4

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

5

2185-1340B

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE COMPRESSEUR

1шт.

6

S2212361

BOLT;SOCKET M10X1.5X35

desc: BOULON A 6 PANS CREUX

3шт.

7

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

3шт.

8

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE

3шт.

9

2520-6003

CONDENSER ASS'Y

desc: ENSEMBLE COMPRESSEUR

1шт.

10

2195-3702

BRACKET;CONDENSER(L.H.)

desc: SUPPORT CONDENSEUR

1шт.

11

2195-3703

BRACKET;CONDENSER(R.H.)

desc: SUPPORT CONDENSEUR

1шт.

12

S0553553

BOLT M6X1.0X35

desc: BOULON A 6 PANS

4шт.

13

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

6шт.

14

S5010313

WASHER;PLAIN M6

desc: RONDELLE PLATE

6шт.

15

S4012333

NUT M6X1.0

desc: ECROU

4шт.

16

2185-1369D1

HOSE;LIQUID(2)

desc: TUYAU FLEXIBLE LIQUIDE(2)

1шт.

17

2185-1371D4

HOSE;LIQUID(1)

desc: TUYAU FLEXIBLE LIQUIDE(1)

1шт.

18

2204-6032

DRIER;RECEIVER

desc: RESERVOIR DESSICATEUR

1шт.

19

2514-6001

HOLDER;RECEIVER DRIE

desc: POSSESSEUR

1шт.

20

S0504853

BOLT M6X1.0X20

desc: BOULON A 6 PANS

2шт.

21

2106-1016D6

BELT;V

SERIAL: 1-170

1шт.

21

2106-1016D9

BELT;V A1460L

SERIAL: 171-613

1шт.

21

2106-1021D9

BELT;V

SERIAL: 614

1шт.

22

2920-9031A

UNIT;AIR HANDLING

SERIAL: 1-179

1шт.

22

2920-9031B

UNIT;AIR HANDLING

SERIAL: 180

1шт.

23

2191-1374D12

PLATE

desc: PLAQUE

4шт.

24

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

4шт.

25

2549-1113D3

SWITCH;AIRCON

desc: INTERRUPTEUR

2шт.

26

2543-9027

CONTROLLER;AIRCON

desc: MODULE DE COMMANDE

1шт.

27

S3450583

SCREW M4X0.7X12

desc: VIS

2шт.

28

S5100103

WASHER;SPRING M4

desc: RONDELLE ELASTIQUE

2шт.

34

2124-1509D6

CLIP Ґх42/M8

desc: ATTACHE

1шт.

35

S4012533

NUT M8X1.25

desc: ECROU

1шт.

36

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

1шт.

37

2124-1084D3

CLIP;BAND

desc: ATTACHE

15шт.

38

S2209063

BOLT;SOCKET M8X1.25X25

desc: BOULON A 6 PANS CREUX

4шт.

39

2114-1058D29

WASHER 26/ 9

desc: RONDELLE PLATE

4шт.
