Запчасти Doosan Daewoo PROPELLING PIPING(1)-TRAVEL MOTOR POWER TRAIN

-

400-01250

PROPELLING PIPING

SC: D

-2шт.

10

2180-1026D19

O-RING

desc: JOINT TORIQUE

2шт.

13

S5110703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

8шт.

14

S2215466

BOLT;SOCKET M12X1.75X40

desc: BOULON DE PLOT

8шт.

16

2181-9081

FLANGE;SPLIT 1-6000PSI

desc: BRIDE

4шт.

17

DS2040363

HOSE PF1-1400L

desc: TUYAU FLEXIBLE

1шт.

36

DS2045319

HOSE PF1-750L

desc: TUYAU FLEXIBLE

1шт.

43

2181-9086

FLANGE;SPLIT 1-6000PSI

desc: BRIDE

4шт.

44

2180-1026D23

O-RING

desc: JOINT TORIQUE

2шт.

45

S2218566

BOLT;SOCKET M14X2.0X45

desc: BOULON DE PLOT

2шт.

46

S2220266

BOLT;SOCKET M14X2.0X130

desc: BOULON DE PLOT

6шт.
