Запчасти Doosan Daewoo ROTARY GROUP-TRAVEL MOTOR HYDRAULIC PARTS

-

09603784

ROTARY GROUP

desc: ROTATOIRE GROUPE

-2шт.

1

09603785

ROTARY GROUP;HYDR. SECTION

desc: ROTATOIRE GROUPE

1шт.

1-1

09430794

CYLINDER

desc: . VERIN

1шт.

1-2

09921790

LENS;CONTROL

desc: . LENTILLE

1шт.

1-3

09921576

PIN;CENTER

desc: . GOUPILLE

1шт.

1-4

02021905

PISONT WITH PISTON RINGS

desc: . PISTON

7шт.

1-4-1

09430790

PISTON

desc: .. PISTON

1шт.

1-4-2

09831897

RING;STEEL SEAL

desc: .. BAGUE

2шт.

1-6

09921577

SHIM;ADJUCTMENT

desc: . CALE

1шт.

1-6

09921578

SHIM;ADJUCTMENT

desc: . CALE

1шт.

1-6

09921579

SHIM;ADJUCTMENT

desc: . CALE

1шт.

1-6

09921580

SHIM;ADJUCTMENT

desc: . CALE

1шт.

1-6

09921581

SHIM;ADJUCTMENT

desc: . CALE

1шт.

1-6

09921582

SHIM;ADJUCTMENT

desc: . CALE

1шт.

1-7

09921583

SPRING;PRESSURE

desc: . RESSORT

1шт.

1-11

09062969

PLATE;RETAINING

desc: . PLAQUE

1шт.

1-12

09831108

SCREW;PAN HEAD

desc: . VIS

14шт.

2

09921597

SHAFT;DRIVE

desc: ARBRE

1шт.

3

09651524

SHIM

desc: CALE

1шт.

6

09650815

PLATE;BACK-UP

desc: PLAQUE

1шт.

6

09921589

PLATE;BACK-UP

desc: PLAQUE

1шт.

6

09921590

PLATE;BACK-UP

desc: PLAQUE

1шт.

6

09921591

PLATE;BACK-UP

desc: PLAQUE

1шт.

6

09921592

PLATE;BACK-UP

desc: PLAQUE

1шт.

6

09921593

PLATE;BACK-UP

desc: PLAQUE

1шт.

6

09921594

PLATE;BACK-UP

desc: PLAQUE

1шт.

6

09921595

PLATE;BACK-UP

desc: PLAQUE

1шт.

6

09921596

PLATE;BACK-UP

desc: PLAQUE

1шт.

7

09083369

RING;RETAINING

desc: RONDELLE DE RETENUE

1шт.

10

09154687

BEARING;TAPERED-ROLLER

desc: ROULEMENT

1шт.

11

09154688

BEARING;TAPERED-ROLLER

desc: ROULEMENT

1шт.
