Запчасти Doosan Daewoo FRONT PIPING FRONT PARTS

-

2400-2103A

FRONT PIPING

SC: D

-2шт.

1

2440-9344A

CYLINDER;BOOM(L.H.)

desc: VERIN DE FLECHE-GAUCHE

1шт.

2

2440-9345A

CYLINDER;BOOM(R.H)

desc: VERIN DE FLECHE-DROIT

1шт.

3

440-00020A

CYLINDER;ARM

desc: VERIN DE BALANCIER

1шт.

4

440-00021A

CYLINDER;BUCKET

desc: VERIN DE GODET

1шт.

5

140-00130

PIPE;ARM CROWD

desc: TUYAU

1шт.

6

140-00131A

PIPE;ARM DUMP

desc: TUYAU

1шт.

7

140-00132A

PIPE;BUCKET CROWD

desc: TUYAU

1шт.

8

140-00133

PIPE;BUCKET DUMP

desc: TUYAU

1шт.

9

140-00134A

PIPE;BUCKET

desc: TUYAU

2шт.

10

124-00011

CLAMP

desc: ATTACHE

6шт.

11

2184-1196D112

HOSE 3/4-950L

desc: TUYAU FLEXIBLE

1шт.

12

2184-1196D156

HOSE 3/4-1500L

desc: TUYAU FLEXIBLE

2шт.

13

2180-1026D2

O-RING

desc: JOINT TORIQUE

3шт.

14

S2212466

BOLT;SOCKET M10X1.5X40

desc: BOULON DE PLOT

8шт.

15

S8030121

O-RING

desc: JOINT TORIQUE

11шт.

16

2161-2250A

RUBBER

desc: CAOUTCHOUC

36шт.

17

2124-1599

CALMP

desc: ATTACHE DE TUYAU

2шт.

18

S0560853

BOLT M12X1.75X55

desc: BOULON

2шт.

19

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

20

195-00178

BRACKET

desc: SUPPORT

2шт.

21

S0515253

BOLT M12X1.75X30

desc: BOULON

2шт.

22

S0565466

BOLT M16X2.0X60

desc: BOULON

14шт.

23

S5102903

WASHER;SPRING M16

desc: RONDELLE ELASTIQUE

14шт.

24

124-00012

CLAMP

desc: ATTACHE

4шт.

25

2184-1200D11

HOSE 3/4-950L

desc: TUYAU FLEXIBLE

1шт.

26

2181-9079

FLANGE;SPLIT 3/4ЎИ-5000PSI

desc: FLASQUE EN DEUX PARTIES

2шт.

27

S2212066

BOLT;SOCKET M10X1.5X25

desc: BOULON DE PLOT

4шт.
