Запчасти Doosan Daewoo MAIN PIPING(5)-TRAVEL BODY PARTS

-

400-01222

MAIN PIPING

SC: D

-2шт.

4

2184-1124D218

HOSE PF1-1800L

desc: TUYAU FLEXIBLE

1шт.

5

2184-1124D172

HOSE-1320L

desc: TUYAU FLEXIBLE

1шт.

6

2184-1250D56

HOSE-1900L

desc: TUYAU FLEXIBLE

1шт.

7

2184-1200D60

HOSE PF3/4-1900L

desc: TUYAU FLEXIBLE

1шт.

27

S2215466

BOLT;SOCKET M12X1.75X40

desc: BOULON DE PLOT

8шт.

28

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON DE PLOT

16шт.

29

2180-1026D19

O-RING

desc: JOINT TORIQUE

4шт.

33

2180-1026D2

O-RING

desc: JOINT TORIQUE

2шт.

34

2181-9079

FLANGE;SPLIT

desc: BRIDE

4шт.

37

S8000181

O-RING

desc: JOINT TORIQUE

2шт.

39

2181-9083

FLANGE;SPLIT

desc: BRIDE

4шт.

42

S8030121

O-RING

desc: JOINT TORIQUE

2шт.

48

2181-9084

FLANGE;SPLIT

desc: BRIDE

4шт.

49

2181-2404A

ADAPTER

desc: ADAPTEUR

2шт.

60

124-00208D7

CLIP

desc: CLIP

1шт.

61

120-00276

BOLT M8X1.25X12

desc: BOULON

1шт.
