Запчасти Doosan Daewoo MAIN PIPING(2)-BOOM BODY PARTS

-

400-01222

MAIN PIPING

SC: D

-2шт.

2

2140-1624A

PIPE;BOOM DOWN

desc: TUYAU

1шт.

3

2140-1625A

PIPE;BOOM UP

desc: TUYAU

1шт.

18

2195-3657

BRACKET

desc: SUPPORT

2шт.

19

S0515353

BOLT M12X1.75X35

desc: BOULON

4шт.

20

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

6шт.

24

S0561053

BOLT M12X1.75X65

desc: BOULON

2шт.

25

2124-1025D5

CLAMP;PIPE

desc: FIXATION DE TUYAU

2шт.

29

2180-1026D19

O-RING

desc: JOINT TORIQUE

2шт.

31

S2212066

BOLT;SOCKET M10X1.5X25

desc: BOULON DE PLOT

16шт.

32

S2212366

BOLT;SOCKET M10X1.5X35

desc: BOULON DE PLOT

4шт.

33

2180-1026D2

O-RING

desc: JOINT TORIQUE

4шт.

34

2181-9079

FLANGE;SPLIT

desc: BRIDE

8шт.

40

S2212666

BOLT;SOCKET M10X1.5X50

desc: BOULON DE PLOT

4шт.

42

S8030121

O-RING

desc: JOINT TORIQUE

4шт.

45

S5010713

WASHER;PLAIN M12

desc: RONDELLE PLATE

4шт.

46

2184-1229D12

HOSE(BOOM)-730L

desc: TUYAU FLEXIBLE

4шт.
