Запчасти Doosan Daewoo HIGH TRACK ASSY OPTION PARTS

-

9604-1056

HIGH TRACK ASS'Y

SC: D

-2шт.

1

9604-1055

FRAME;TRACK

desc: TRAIN DE ROULEMENT

1шт.

2

109-00028C

BEARING;SWING

desc: PALIER

1шт.

3

401-00034A

TRAVEL;MOTOR

desc: MOTEUR DE TRANSLATION

2шт.

4

2108-1019E

SPROCKET

desc: COURONNE DENTEE

2шт.

5

K1001027

TRACK SPRING ASS'Y

desc: ENSEMBLE TENDEUR DE CHENILLE

2шт.

6

270-00016

IDLER ASS'Y

desc: BARBOTIN

2шт.

7

2270-9403A

ROLLER

desc: GALET

20шт.

8

9273-6010D7

TRACK SHOE ASS'Y

desc: MAILLON DE CHAINE

2шт.

9

S0765866

BOLT (M16x1.5x80)

desc: BOULON A 6 PANS

16шт.

10

2480-6043

JOINT;CENTER

desc: JOINT TOURNANT

1шт.

11

2623-4002B

GUARD;LINK

desc: BARRE DE PROTECTION

2шт.

12

2621-1428

COVER

desc: COUVERCLE

1шт.

13

2403-1002

COVER

desc: COUVERCLE

1шт.

14

2180-1017A

PACKING

desc: EMBALLAGE

1шт.

15

621-00236

COVER

desc: COUVERCLE

2шт.

16

2114-1816A

WASHER;HARDENED

desc: RONDELLE

60шт.

17

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

36шт.

18

S5102903

WASHER;SPRING

desc: RONDELLE ELASTIQUE

8шт.

19

9627-1014

PLATE

desc: PLAQUE

8шт.

20

2185-2527AD7

STEP (700mm SHOE)

desc: MARCHE

4шт.

21

2114-9012A

WASHER;HARDENED

desc: RONDELLE

36шт.

22

2120-2196D1

BOLT;SET

desc: BOULON A 6 PANS

2шт.

23

2120-2196D2

BOLT;SET

desc: BOULON A 6 PANS

12шт.

24

2420-1242A

VALVE;GREASE

desc: VANNE

2шт.

25

S0515353

BOLT (M12x1.75x35)

desc: BOULON A 6 PANS

36шт.

26

120-00050B

BOLT;FLANGE

desc: BOULON A 6 PANS

42шт.

27

S0565566

BOLT (M16x2.0x65)

desc: BOULON A 6 PANS

60шт.

28

S0721466

BOLT (M16x1.5x40)

desc: BOULON A 6 PANS

8шт.

29

S0766066

BOLT (M16x1.5x90)

desc: BOULON A 6 PANS

64шт.

30

S0770266

BOLT (M16x1.5x70)

desc: BOULON A 6 PANS

36шт.
